Lightolier QVH2GPFOS2FT Specification

Page 1 of 2
Features
• Efficiency 52.6%.
• Shallow plenum depth.
• Swing down microperforated lamp shields for easy relamping and
maintenance.
• Alter soft white film on inside of mesh conceals lamp image and
provide balance between reflected light and direct light.
• 95% Reflective Alter soft white paint finish.
• Specular interior reflector.
• One piece body for easy installation.
• Easy access to ballast through lamp compartment.
• Fits standard T-Grid ceilings.
• Optional acrylic drop-down visual element
• Slim Semi-Recess and Slim Surface luminaires have the same
photometric performance data.
Mounting Methods / Features
Ceiling compatibility
Suited to standard exposed
T-grid ceilings
Swing down optical system for
easy relamping and maintenance
Microperforated mesh
lamp shields
ALTER SOFT LIGHTS
2'x2' SLIM SEMI-RECESSED DIRECT/INDIRECT FLUORESCENT
Suited to standard exposed
Slot T-grid ceilings
Shallow plenum depth
2-1/4"
3-15/16"
(57mm)
(100mm)
Slim Surface
qvf2spfos2FT
MOUNTING
BRACKET
SPRING CONTOURED
SURFACE FRAME
3-15/16" 2-1/4"
CEILING
(100mm) (57mm)
25-9/16"(650mm) Width
24"(610mm) Length
Slim Surface and Slim Semi-Recessed
have the same photometric performance
data.
QVH2GPFOS2FT
2 LAMP, TT5 BI-TUBE, 2 1/4'' RECESSED CEILING DEPTH
MICROPERFORATED MESH LAMP SHIELD, STATIC
Dimensions
23-13/16"(605mm)
23-13/16"(605mm)
T-BAR
Job Information
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
Lightolier
a Genlyte Thomas Company
Technical Information: (978) 657-7600 • Fax (978) 658-0595
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division)
A0902
2-1/4"
(57mm)
1-11/16"
(43mm)
Type:
www.lightolier.com
Section 5 / Folio L85-10
