Lightolier HS Series Specification

S -C
ELF ONTAINED
HSCTHF6012
22.0"
(56.0 cm)
11.3"
(28.7 cm)
E
XPLOSION
Features
Illumination: Illumination is
accomplished with three
12 V, 20 W MR16 halogen
lamps. Each high-intensity lamp
can be independently adjusted
to provide custom emergency
lighting to a specific area.
Housing: Copper-free cast
aluminum enclosure designed
to withstand the pressure
of explosions generated
by internal arc without
propagating them into the
hazardous atmosphere.
Enclosure has a corrosion
resistant, epoxy powder coat
finish. Includes high-impact,
heat-resistant globe with a
cast aluminum globe guard,
and stainless steel external
hardware. Ceiling and wall
mount fixtures have universal
junction box with four tapped
holes for 3/4" rigid conduit
(3 close-up plugs provided).
Pendant mount fixture has
3/4" top hub. Optional exit
accessory is available.
HS Series
-P L
ROOF IGHTING
Electronics: 120/277 VAC
dual voltage input with surge-
protection, solid-state circuitry
provides for a reliable charging
system. Charging system is
complete with low voltage
disconnect, AC lockout,
brownout protection, AC
indicator lamp and remote
hazardous location test switch.
Electrical Specifications:
60 W (120 VAC)
60 W (277 VAC)
Job Information Type:
Job Name:
Cat. No.:
Notes:
F
IXTURE
Page 1 of 2
Code Compliance
UL 924 and 844 listed. NFPA
70 and NFPA 101, NEC,
BOCA, OSHA and IBC
illumination standards. Suitable
for use in Class I, Div. 1,
Groups C & D, Zones 0, 1 &
2, Groups IIA, IIB + H & IIC;
2
Class I, Div. 2, Groups C & D,
Zone 2, Groups IIA, IIB + H
IIC; Class II, Div. 1, Groups E,
F & G; Class II, Div. 2, Groups
F & G; and Class III hazardous
location areas. Rated for use in
NEMA 7CD and 9EFG areas.
Temperature performance
ratings (maximum ambient
temperature 160°C): -T6 (Class
I), T5 (Class II).
&
2
