Lightolier Lytecaster 1149 Specification

# 1013
Page 1 of 2
11 5/8"
BR40
10 7/8"
PAR38
Complete Fixture consists of Reflector Trim & Frame-In Kit. Select each separately.

Reflector Trim

Frame-In Kit — See Individual Frame-In Kit Specification Sheets
1149 Specular Black

Frame-In Kit Installation Type Lamping

1150 Specular Gold
1102P1
1151
Specular Clear
1103R
1151CD Clear Diffuse

Features

1. Deep Reflector: Hydroformed aluminum, .040" thick (16 ga.); specular clear,
gold or black finish; matte white trim flange. Depth provides 40˚ shielding
angle.
2. Frame-In Kit: (1102P1 standard frame shown) Other frames listed above and
shown on the right. See Frame-In Kit specification sheets for more details.
Lytecaster
6 3/4" Aperture Deep Reflector - BR & PAR Lamp Reflector Trim
6 1/2"
Non-IC 150W PAR38*
Non-IC BR40
Remodeler 250W PAR38
*Cool Beam
Recessed Downlighting
®
11 5/8"
10 7/8"
1 1/4" Max.
1149/1102P1 Series
Standard Incandescent
Incandescent
Height
11 5/8", 10 7/8"
11 5/8", 10 7/8"

Labels

UL (Suitable for Damp Locations), I.B.E.W.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte company
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2007 Genlyte Group LLC • H0407
1149/1103R
Non-IC Remodeler Ring
Type:
www.lightolier.com
1149
