Lightolier Lytecaster 413X Specification

Page 1 of 2
4 1/2"
Complete Fixture consists of Reflector Trim & Frame-In Kit. Select each separately.
Reflector Trim
413BKX Black Paint
413MTX Metal Paint
413SBX
Satin Brass Plated
413STX
Stainless Steel Plated
413WHX White Paint
Features
1. Housing: 25ga. galvanized steel.
2. Residence Mounting Clip: Factory-installed ; zinc plated spring steel ;free-
hand installation.
3. Flange Housing: Cold rolled steel 22ga.
4. Adjustable Lampholder Support: 27ga. steel ; Rotates 358° horizontaly
and 0° to 30° vertically.
5. Mounting Clips (2): 24ga. spring steel, zinc plated. Provide easy snap-in
/snap-out action.
6. Lamp Guard: 2" (51mm) dia. borosilicate glass.
Frame-In Kit
Note: For complete Frame-In Kit specifications, see 400 frame
specification sheets.
Labels
CSA, UL (Suitable for damp Locations)
Accessories
Square Face Plate
400SQBK Black
400SQWH White
Lytecaster
1/8"
5 1/2"
Recessed Downlight
®
4 3/4" (121mm) Aperture Gimbal M16
1" MAX
Ceiling Cutout:
Frame-In Kit Lamp
Remodeler 400MRX 75W MR16
Remodeler 3401MREX 50W MR16
Non-IC 402MRX
75W MR16
Non-IC 402MREX
75W MR16
IC 402MRIC9X 50W MR16
Non-IC 602MR 75WMR16
Non-IC 603MR 75WMR16
Non-IC 604MR 75WMR16
Non-IC 604SQMR
75WMR16
Alzak is a registered trademark of ALCOA.
®
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte company
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2011 Genlyte Group LLC • C0711
413X
Type:
www.lightolier.com
