Cooper Lighting PORTFOLIO M8005 Specification

Dimensions Depth
M8005 17-1/4"
M8015 17-1/4"
HOUSING
M8005=HID Round Wall Mount
M8015=HID Soft Square Wall Mount
MH
9-5/8"
HPS
9-5/8"
Housing, Ballast, Trim, Accessories and Lamps ordered as separate line items.
10" Wall Mount Cylinder
O.D. Height
9-5/8" 14-1/2"
Metal Halide & HPS
9-5/8" 14-1/2 "
Medium or wide beam wall mount
cylinder or soft sided square
downlight using a single vertically
mounted ED23.5 high pressure
sodium or ED28 metal halide mogul
base lamp. Integral safety glass
provides lamp containment for
unprotected metal halide lamps.
Magnetic core and coil ballast
ordered separately installs rapidly
inside fixture arm using electrical
FINISH
P=White
BZ=Bronze
MB=Matte Black
TRIM
55000=Reflector
TRIM
75000=Reflector
Ordering Example
ED23.5
ED28
quick connects.
BALLAST
757=175W MH 120/277V Magnetic
7576=175W MH 347V Magnetic
637=70W HPS 120/277V Magnetic
6376=70W HPS 347V Magnetic
647=100W HPS 120/277V Magnetic
6476=100W HPS 347V Magnetic
657=150W HPS 120/277V Magnetic
6576=150W HPS 347V Magnetic
FINISH
LI=Low Iridescent Clear GP=Graphite
H=Haze GPH=Graphite Haze
G=Gold K=Cognac
WH=Wheat KH=Cognac Haze
WMH=Warm Haze BA=Black Baffle
W=Gloss White
B=Black
FINISH
LI=Low Iridescent Clear GP=Graphite
H=Haze GPH=Graphite Haze
G=Gold K=Cognac
WH=Wheat KH=Cognac Haze
WMH=Warm Haze BA=Black Baffle
W=Gloss White
B=Black
Housing
M8015P
PORTFOLIO
HOUSING
10"
M8005
M8015
TRIM
Downlight
175W Max ED28 MH
Medium or Wide Beam
Downlight
150W Max ED23.5 HPS
Wide Beam
Ballast Trim
757 55000KH
COOPER LIGHTING
™
899
