Cooper Lighting METALUX F-BAY 2HBG Series Specification Sheet

D I M E N S I O N S
2' x 4', 4 LAMP
23-3/4" [603mm]
2' x 4', 6 LAMP
23-3/4" [603mm]
O R D E R I N G I N F O R M AT I O N
S A M P L E N U M B E R : 2 H B G - 6 5 4 T 5 - A - U N V - E B T 2 - U
Width
2=24"
Series
HB=High Bay
Trim Type
G=Grid/Lay-in (Standard)
F=Flange Trim
No. of Lamps
4=4 Lamps
6=6 Lamps
Lamp Type
32=32W T8 Lamps (48")
28T5=28W T5 Lamps (48")
54T5=T5HO Lamps (48")
Distribution Optic
Blank=Aisle (Specular Aluminum)
G=General (White Painted)
(1)
NOTES: Products also available in non-US voltages and frequencies for international markets.
(3)
Voltage to be specified when using cord & plug.
For complete product data, reference the Fluorescent Specification binder. Specifications & dimensions subject to change without notice. Consult your Cooper Lighting
Representative for availability and ordering information.
COOPER LIGHTING - METALUX
D E S C R I P T I O N
The 2HBG series is an outstanding
solution for high mounting height
5-5/8"
industrial or retail applications that
[143mm]
require recessed luminaire. The 2HBG
optic has been optimized to provide
maximum performance from either T5
or T8 lamps. The 2HBG's high lumen
package allows the benefits of
fluorescent to be applied to
applications requiring a recessed
luminaire used at high mounting
5-5/8"
heights. The primary benefits include
[143mm]
exceptional color rendering, high
system efficacy, 95% lumen
maintenance, long lamp life, instant
on/instant re-strike, economical
dimming, and uniform brightness
control. Primary applications include
"big box" retail, shopping malls, light
industrial, etc.
Downlight Optic
Blank=Open
Ballast Type
A=Prismatic Acrylic
Lens & Aluminum EB8 = T8 Electronic Instant Start.
Doorframe
CL=Clear Acrylic
No. of Ballast
Lens & Aluminum
2
Doorframe
EB8 /PLUS= T8 Electronic Instant Start.
No. of
(1)
Voltage
Ballast
UNV=Universal
2
120/277 Voltage
UNC=Universal ER8 = T8 Electronic Program Rapid Start.
347/480 Voltage (T5 linear only)
(3)
120V=120 Volt
No. of Ballast
(3)
277V=277 Volt
2
(3)
347V=347 Volt
EBT =T5 Linear Electronic Program Rapid
Options No. of Ballast
2
GL=Single Element Fuse
(For complete details on generic or to specify
GM=Double Element Fuse
manufacturer's ballast see pg. 469)
Lamps - for lamps installed,
see lamp options table
Emergency (T8 only) - for EM
installed, see EM options
(2)
table
(2)
Not available when specifying emergencies, voltage must be specific.
Packaging
Options
(See Options & U=Unit Pack
(1) Accessories Section)
PAL=Job
Pack, out of
carton
Total Harmonic Distortion < 10%
PALC=Job
Pack, in
carton
High Ballast Factor >1.13. Total
Harmonic Distortion < 20%
Total Harmonic Distortion < 10%
Start. Total Harmonic Distortion < 10%
®
F-BAY 2HBG
SERIES
R e c e s s e d
2 ' x 4 ' H i g h - B a y
4 o r 6 L a m p
R E C E S S E D H I G H - B AY
I N D U S T R I A L L U M I N A I R E
• Specular enhanced
aluminum standard for
optical distribution. White
painted optics optional
• Available as open optics or
lensed with reinforced
aluminum door, mitered
corners
• Four auxilary fixture end
suspension points
provided
• End plate grid lock feature
• Superior lumen
maintenance exceeds that
of HID 90-95% of initial light
output at end of life
• Instant strike and re-strike
ability
• Occupancy sensor is
available to instantly turn
lights on and off. Saves
more energy!
• UL/CUL Listed. Suitable for
damp locations
COOPER LIGHTING
447
