1.2 - Unpacking

Remove the CR3 from its packing and inspect it for damage. If the scanner was damaged during shipping,
please call Code at (801) 495-2200.
The standard CR3 unit is shipped with a USB cable interface. The unit also features a 1950 mAH battery
that must be installed in the unit at all times.
Various accessories are available for the CR3.
• 4 cable options (USB 6 ft., USB 12 ft., RS232 or PS/2)
• Class 1 Bluetooth radio with 300 foot operating range (shorter range option available)
• Clip-on pistol grip handle
• Ruggedized cabled handle
• Battery handle (in two battery sizes)
• External battery charger
• CodeXML Bluetooth modem
• Protective Case Cover
• Power Supplies: US/Europe/SA/UK/Asia
• Reader Stand
• Lanyard Hook attachment option
Please keep your packing materials. The CR3 is shipped in an approved shipping container and should be
used if you ever need to return your equipment for servicing.
1.3 - Powering On/Off Reader
To power on the reader, press and hold either of the red trigger buttons for 3 seconds (Figure 1.1).
The reader will power down after 2 hours of non-use. To change the default settings, please see Section
4.7 - Reader Sleep/Time Out settings.
Figure 1.1
