Lightolier Walmaster WMRL143120SO Specification

Page 1 of 2
Features
• Low iridescent semi- specular reflective system for precise
controlled light output.
• Evenly lights vertical surfaces or displays (no scallops).
• Less than 3:1 maximum to minimum wall illumination when
installed 6 feet on center.
• 20,000 hours lamp life
• Energy saving T8 lamp..
• No edges protrude below ceiling line.
• Can be installed only 2 feet from wall to farthest edge of fixture (3
feet maximum).
• Fits all standard and narrow grid ceiling systems.
• One-piece body and integral hanger for easy, quick installation.
• Sides of fixture can support tile or sit on T-bar.
• UL-Listed access plate.
• Meets NYC Code requirements.
Features
Mounting Methods
narrow grid.
1-1/2"
standard grid
1-1/2"
9/05
High Performance, 4', Recessed Wallwasher/Accent Light
integral hanger
WMRL143120SO
Walmaster
Dimensions
Job Information
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
Lightolier
a Genlyte Company
Technical Information: (978) 657-7600 • Fax (978) 658-0595
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2005 a Genlyte company
One T8 Lamp
Type:
www.lightolier.com
Section 5/Folio K10-17 Rev. A
