17" (432mm)
Ordering Information
EG
L
Series
Lamps
EG = Edge
L = LED 8x1w
Example = EGL–SBE
Mounting Options
Edge Clamp (E):
Panel Bracket (P):
Clamps onto edge
Attaches to 1" slotted panel
of desk or table.
standard. Consult factory for
furniture compatibility.
Features
Lamp: 8x1w LEDs (4800K). LEDs included.
Electrical: Wired for 120V 60Hz operation.
Transformer: In-line 370 ma transformer with quick connect cord. Primary input:
120V. Secondary output: 12V.
Power Cord: Quick connect. Minimum 6ft (182mm) long.
Arm: Formed steel, 34" spring-balanced double arm and 17" single arm versions
are available.
Shade: Heavy-duty cast aluminum shade with internal reflector and
prismatic lens.
Finish: Matte black or silver enamel.
Listing: UL/cUL listed.
Lightolier is a Philips group brand
17" (432mm)
Arm
Color
Mounting
S = 17" Single Arm
B = Black
E = Edge Clamp
L = 34" Double Arm
S = Silver
P = Panel Bracket
S = Slat Wall Bracket
T = Table Base
Z = Zero Clearance
Slat Wall Bracket (S):
Attaches to many furniture slat
wall systems. Consult factory for
furniture compatibility.
17" (432mm)
5 1/2" (140mm)
Bracket
Table Base Heavy (T):
9" diameter weighted base for
desktop use.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • B1208
Task Lighting
LED Task Light
2 1/4" (57mm)
8 3/8" (213mm)
Zero Clearance Bracket (Z):
Two-piece edge clamp for tight
spaces. Clamps onto edge of desk
or table.
Type:
Edge
