Lightolier Lytecaster 1113IE Specification

Page 1 of 1
7 3/16"
Complete Fixture consists of Frame-In Kit and Reflector Trim. Select each separately.
Reflector Trims
Catalog No. Description
1113IE 6 ¾" Open Downlight - Integrated Emergency - Specular Clear
1113CDIE 6 ¾" Open Downlight - Integrated Emergency - Clear Diffuse
1113WHIE 6 ¾" Open Downlight - Integrated Emergency - Matte White
Features
1. Reflector: Hydroformed aluminum, .040" minimum thickness; Anobrite®
(anodic-processed) semi-specular finish for permanent reflectivity; matte
white trim flange.
2. Aperture Cone: Aluminum cone painted or anodized finish.
3. Frame-In Kit: See Frame-In Kit specification sheets for more
information.
Options & Accessories
Extra Wide Flange Trim Ring: 1954 - 8-5/8" O.D.
Lytecaster Recessed CFL Downlighting
®
6 ¾" Aperture, Cone Reflector, Integrated Emergency, Reflector Trim
6 1/4"
7 9/16"
Compatible Frame In Kits
(See Individual Frame-In Kit Specification Sheets)
Catalog No.
1101F2642UEL
Labels
cULus Listed. Suitable for Damp Locations. I.B.E.W.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2007 Genlyte Group LLC • A1207
Installation Type
Uniframe Non-IC High-Lumen
™
Emergency 120/277V
Type:
a Genlyte company
1113IE
Lamping
26W Quad/Triple
32W Triple
42W Triple
www.lightolier.com
