Lightolier LytePoints 56946 Specification

Page 1 of 1
2.00" Max.
(50.8mm)
2.00"
(51mm)
.394"
(10mm)
.0886"
(22mm)
Description Coating Watt
50ES16NFLX/120 Aluminum 50
Features
1. 120V 50W NFL, 2000 hours average life
2. Compact size, ES16 is the same size as a 12 volt MR16
3. "W" shaped vibration resistant filament.
4. Turn and lock base allows front relamping with certain trims
5. Can be dimmed with standard incandescent dimmers
6. Aluminized reflector for cool operation
7. Integral cover glass for added safety
8. High CRI provides excellent color rendering
1400 lx
350 lx
155 lx
2.25"
(57mm)
88 lx
Volt Base Beam
120 GU-10 25 Deg.
LytePoints
25°
1 m
2 m
3 m
Ø 440mm
4 m
Ø 880mm
Ø 1320mm
Ø 1780mm
CBCP Avg Life Length
1400 2000 Hrs 21/4"
Frame-in Kits
Compatible with 300ES, 302ES and 302ESIC Frame-In Kits
For Frame-In Kit information see separate specification
sheets
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte Thomas Company
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division) • A0902
56946
® Accessory
Line Voltage 120V ES16 Lamp
1500
1250
1100
750
500
250
0 10 20
30 20 10
Diameter Case
2" 15
Type:
www.lightolier.com
30
