3 Repeat the above two steps to place any number of objects on the layout.
Recommended: Place the objects in such a way that the physical layout is well represented in the Layout with minimum number of
objects.
5.3 Managing Objects within the Layout
You can manage objects and their properties on the layout in Planner.
5.3.1 Selecting Objects
To select an object, click on the Toolbar.
To select more than one object, do one of the following:
•
Use the Control key.
•
Drag the mouse over the target area to enclose the objects within a dotted outline. This selects all the objects within or
touching the dotted outline.
5.3.2 Moving an Object
To move an object, select and drag it to the desired position.
5.3.3 Changing the Properties of an Object
Planner provides objects of different shapes and thickness.
Figure 35. Layout Object Properties
To change the properties of an object, double‐click or right‐click the object and select Properties.
Menu and Toolbar Options
