Appendix C: File Level and Application Level Parameters
The following section presents an overview of the File level and the Application level parameters.
Table 1 File Level Parameters
File Level Parameters
Accuracy
RSSI Calibration
Spillage Factor
Min Attenuation Factor
Max Attenuation Factor
Alpha
Beta
Table 2 Application Level Parameters
Application Level
Parameters
Coverage Estimation
Thresholds
Sensor Detection
Threshold
Sensor Redundancy
Sensor Prevention
Thresholds
Device Transmit Power
Channel View Threshold
AP Redundancy
In addition to these parameters, Planner also has the following application level parameters:
1 Region Settings in Tools Settings Preferences AP Views
2 Default Access Point Settings
3 Auto Channel Select
4 'Do not show this window again' messages
5 Color Palettes
6 Report Base Folder
Note: The default installation values are selected when you install a new version of Planner.
110
Appendix C: File Level and Application Level Parameters
Data Type Default Value
Integer 1
Integer -10 dB
Positive Integer 2
Real 2
Real 2
Real -4
Real 0.08
Data Type Default Value
-40, -50, -55, -60
Integer
dBm
Integer -85 dBm
Integer 1
-65, -60, -55 dBm
Integer
(low<medium<high)
Integer 13
Integer -85 dBm
Integer 1
3Com ® AirProtect Planner User Guide
Minimum
1
-40 dB
2
1.6
1.6
Not applicable
Not applicable
Minimum
-100 dBm
-150 dBm
1
-150 dBm
0
-150 dBm
1
Maximum
4
40 dB
3
4
4
Not applicable
Not applicable
Maximum
-10 dBm
-20 dBm
10
-20 dBm
20
-20 dBm
10
