Lightolier Lytespan 8266 Specification

Page 1 of 1
Ordering Information
Catalog Number
8266BK
Features
1. Transformer: Electronic. 120V 60Hz input for 20-50W load. .95 power factor.
2. Track Attachment Fitting: Molded polycarbonate; rotates into track?
3. Brass Contact: Extends for connection to second circuit (Advent Lytespan
track only)
4. Transformer Housing: Die cast aluminum
5. Yoke: Steel
6. Lamp Holder: Housing steel. Rotates lamp 90°.
7. Hinge: Allows lamp holder housing to open for re-lamping while staying
attached to housing.
8. Housing: Aluminum no open holes.
9. Spade Terminals: Brass with silicone rubber insulators. Fastens to lamp
terminals.
Finish
All Painted finishes are baked enamel.
Dimming
Use only dimmers specifically designed for use with electronic transformers.
Low voltage fixtures may produce audible sound when dimmed.
Lightolier is a Philips group brand
4
5
8
3
(127mm)
1 3/4
(44mm)
3 3/8
(86mm)
4 5/16 DIA.
6
5 5/8 DIA.
Finish Mounting
Black For use with Lytespan Basic, Advent, and Radius Track. Not compatible with
extension wands or sloped ceiling adapters.
Lytespan Track Lighting System
3 7/8
(98 mm)
3
1
1 3/4 Hx 1 1/4W
44mmH x 32mmW
4 3/16 x 1 1/32W
106mm x 26mmW
3 7/16 DIA.
(87mm)
(214mm)
5 1/8
(130mm)
(110mm)
(143mm)
Accessories
One AF3 Diffusion or AL3 Series
Labels
UL Listed
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • A0708
Theatrical Low Voltage Lytespot
9
8 7/16
9
(229mm)
7
Lamps
12V PAR36 50W Max
(Not included)
Type:
8266
