Lightolier Lytespan 8292WECY Specification

Page 1 of 2
ø

Ordering Information

Catalog No. Voltage Finishings Mountings
8292WEWHCY 120 Matte White
8292WEWHCY2 277 Matte White

Features

1. Ballast Housing: 0.09" extruded aluminum housing with die cast endcaps.
2. Ballast: High power factor electronic metal halide ballast.
3. Reflector Housing: .095" thick extruded aluminum body with die cast end
caps.
4. Vertical Pivot: 0 - 90° vertical adjustment.
5. Mounting Arm: 0.07"extruded aluminum housing.
6. Canopy: 0.06" aluminum canopy.
7. Cross Bar: 0.74" galvanized steel with positive rotation stop provides 350°
rotation and positive lock every 45°. Mounting to J-box provides simple
hands-free wiring.
8. Sockets: 5 Kv pulse rated sockets with nickel plated contacts; leads
enclosed in silicone coated fiberglass sleeving.
9. Wall Washer Reflector: Asymmetrical aluminum reflector with internal
kick reflector provides even illumination on surface.
10. Safety Interlock Switch: Disconnects power when safety lens is removed.
11. Safety Lens: Tempered 1/8" UV filtering glass. Meets or exceeds safety
requirements for metal halide lamps.
12. Indicator Guide: Aiming indicator assures consistent and precise multiple
unit alignment.
13. Supply Leads: 18ga.,SF-1.

Electrical

8292WEWHCY 8292WEWHCY2
Electronic Ballast Electronic Ballast
Input Voltage: 120V, 60Hz Input Voltage: 277V, 60Hz
Power Factor: >95% Power Factor: >95%
Input Power: 78W Input Power: 79W
Input Current: .67 amp Input Current: .29 amp
Harmonic Distortion: <10% Harmonic Distortion: <10%
Do not use on a dimming circuit.
Lytespan ® Track Lighting System
PowerArc
This fixture is intended for ceiling mounting and
surface wall mounting 5' or greater from floor. It is
suitable for use in either dry or damp locations.

Options and Accessories

Accepts PowerArc Accessory Holder (8293AC), Vertical Blade Louver (8293LV),
Spread Lens (8293BE) UV Filter (8293UV), and Visor (8293VS).
NOTE: 8293UV or 8293BE must be combined with 8293AC.
Finish
All painted finishes are baked enamel.
Labels
UL, cUL (Suitable for Damp Locations)
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division) • B0902
™ Canopy Double Ended Metal Halide Wall Washer
12
Lamps
70W CDM or CMH T-6
Double Ended Metal Halide (M-98)
Type:
a Genlyte Thomas Company
8292WECY
www.lightolier.com
