Lightolier Lytespan 8248 Specification

Page 1 of 1
ø1 13/16"
2
1
4 1/4"
ø5 9/16"
Ring PAR38 with Par-Tech ®
Incandescent/halogen
Fixture 8201
7 9/16"

Ordering Information

Catalog No. Finishes
8248 WH Matte White
8248 TM Dark Titanium
8248 NM Natural Metal
8248 BK Matte Black

Features

1. Shade: Die-cast aluminum.
2. Neck Flange: Cold rolled steel, zinc-plated. Used to attach shade to fixture,
without tools.
3. Groove: To connect optional Accessory Holder to shade.

Options and Accessories

PAR38 Accessory Holder (8595) & Accessories (AF4 & AF4HC Series). Order
separately (See Lightolier Specification Sheet 8595).

Finish

All painted finishes: White, Titanium, or Black baked enamel. Natural Metal is
Brushed Metal with protective Clear Coat.

Labels

UL, I.B.E.W.
3
Ring PAR38 with Par-Tech
Incandescent/halogen
Fixture 8202
8 1/8"
6 1/8"
Lamps
INCANDESCENT: PAR38 250W Max. 150W Max. with Accessories (When used on Fixtures 8701 & 28701)
INCANDESCENT: PAR38 150W Max. (When used on Fixtures 8201 & 8202)
METAL HALIDE: PAR38 70W (When used on fixture no. 8706E)
METAL HALIDE: PAR38 100W (When used on fixture no. 8707E)
Lytespan
Metallics
Ring PAR38 with Metallics
Fixtures 8701 & 28701 (ProSpec)
11 1/4"
Ring PAR38 with Metallics
Fixtures 8706E & 8707E
®
11 1/4"
6 1/8"
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte Thomas Company
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division) • A0902
® Track Lighting
TM Par-Tech ® PAR38 Ring Shade
TM Incandescent/Halogen
3 9/16"
2 9/16"
9"
Electronic Metal Halide
TM
3 9/16"
3 3/16"
9 5/8"
Type:
www.lightolier.com
8248
