Lightolier SS 2 LAMP Specification

SS Staggered Strip Surface Fluorescent
Page 1 of 2
Features
• Full 3" overlap eliminates shadows caused by lampholders or lamp
ends.
• Housing is only 1-5/8" deep.
• Safe-handling metal edges.
• Fully enclosed wireway.
• Excellent for perimeter cove lighting or other applications where
continuous even illumination is required.
Dimensions
4-1/4" (108mm)
6-1/2"
3"
(165mm)
(76mm)
38-15/16" (989mm)
4-1/4" (110mm)
6-1/2"
3" (76mm)
(165mm)
25-15/16" (659mm)
4-1/4" (110mm)
1-1/8"
3" (76mm)
(29mm)
4-1/4"
(108mm)
1-1/8"
3"
(29mm)
(76mm)
6-1/2"
(165mm)
19-15/32"
(494mm)
4-1/4"
74-15/16" (1903mm)
(108mm)
3"
1-1/8"
(76mm)
(29mm)
6-1/2"
(165mm)
19-15/32"
(494mm)
4-1/4" Wide, 1-5/8" Deep, 27", 39", 51", 75", 99" Length, Individual or Tandem,
50-15/16" (1294mm)
3" (76mm)
6-1/2"
(165mm)
25-1/2" (648mm)
3" (76mm)
12-15/16"
6-1/2"
(329mm)
(165mm)
19-15/32"
(494mm)
3" (76mm)
6-1/2" (165mm)
98-15/16" (2513mm)
12-15/16"
2" dia. K.O.
1-1/8"
(329mm)
(29mm)
43-1/2"
(1099mm)
3" (76mm)
12-15/16"
1-1/8"
6-1/2"
(329mm)
(29mm) (165mm)
19-15/32"
(494mm)
3-3/4" (T12)
(95mm)
3-1/2" (T8)
(89mm)
3"
(76mm)
6-1/2"
(165mm)
19-15/32"
(494mm)
Job Information
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
Lightolier
a Genlyte Thomas Company
Technical Information: (978) 657-7600 • Fax (978) 658-0595
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2003 Genlyte Thomas Group LLC (Lightolier Division) B0403
SS 2 LAMP
2 Lamp T8 or T12
4-1/4"
(110mm)
1-5/8"
(41mm)
Type:
www.lightolier.com
Section 3A/Folio H130-12
