Newcon Optik DN-140 Operation Manual

Night vision rifle scope (camera/video adaptable)
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
Enlarged version
11.
ACCEPTANCE CERTIFICATE
NIGHT VISION DEVICE
Serial Number _______________________________
Model
DN-140
corresponds to technical conditions ADSH 3.807.020 TU
and is admitted for use.
Date of production -____________________
Place for seal
Quality inspector ____________________
(signature)
16
OPERATION MANUAL
NIGHT VISION RIFLE SCOPE
DN-140M
(Camera/Video Adaptable)
In USA : 3310 Prospect Ave. Cleveland, OH 44115
In Canada : 1183 Finch Ave. W., Suite 302, Toronto, ON. M3J 2G2 Canada
Tel: (416) 663-6963 Fax: (416) 663-9065
Email: NEWCONSALES@NEWCON-OPTIK.COM
INTERNET: http://WWW.NEWCON-OPTIK.COM

Advertisement

loading
Need help?

Need help?

Do you have a question about the DN-140 and is the answer not in the manual?

Questions and answers

Related Manuals for Newcon Optik DN-140

Summary of Contents for Newcon Optik DN-140

  • Page 1 ACCEPTANCE CERTIFICATE NIGHT VISION DEVICE Serial Number _______________________________ OPERATION MANUAL Model DN-140 corresponds to technical conditions ADSH 3.807.020 TU and is admitted for use. Date of production -____________________ Place for seal Quality inspector ____________________ (signature) NIGHT VISION RIFLE SCOPE DN-140M (Camera/Video Adaptable) In USA : 3310 Prospect Ave.
  • Page 2 The use of this device might be restricted or forbidden in USE, EXCEPT AS EXPRESSLY SET FORTH NEREIN. THE your area. Check with local authority. Newcon Optik will SOLE OBLIGATION OF NEWCON UNDER THIS LIMITED not accept any responsibility for improper usage of this WARRANTY SHALL BE TO PEPAIR OR REPLACE THE scope.

  • Page 3: Warranty

    Please include a cheque or money It is allowed to turn on the unit at daytime, order made out to NEWCON OPTIK for the amount of US$7.50 but the lenses must be covered by caps. to cover shipping and handling.

  • Page 4: Troubleshooting

    NEVER 8. TROUBLESHOOTING • aim active unit at intense light sources (i.e. lights, headlamps, campfires, the moon, etc.)3 The scope does not work. NEVER • reverse the polarity of a battery - Check that the batteries are installed properly. - Check the charge of the batteries. Replace if they are weak. Do not use old batteries with new ones.
  • Page 5 7. Next, focus the scope by turning the focus ring on the starlight or man-made light. The scope was designed to be sight’s ring. You may have to re-focus both lenses to easy to use, and provide many years of operation. achieve sharp focus.
  • Page 6 Warning! 6.3 Operation at night AT INSUFFICIENT AMBIENT After transportation or keeping the device at temperature ILLUMINATION lower than -40°C (-40°F), the device must be warmed up to At insufficient ambient illumination use the ambient temperature, from -10°C (14°F) to +40°C (104°F), Infra/Red illuminator (5).

  • Page 7: Optional Accessories

    6. OPERATION INSTRUCTIONS 3. COMPONENTS WARNING! NEVER DIRECT THE LENS IN THE DIRECTION DN-140 is supplied with the following components: OF BRIGHT LIGHT! 6.1 Pre-starting procedures. NAME QUANTITY Unpack the device. In order to install the DN-140 unit batteries, open battery house cover (4), and install the Case batteries.
  • Page 8 SPECIFICATIONS OF DN-140 5. CONSTRUCTION Image intensifier Gen. 1 Resolution ln/mm 32ln/mm Magnification, X Field of View, angl.., degrees, not less 12° Lens 85mm, F/2 Dioptric correction +3, -4 Focus Range, m 0.6-∞ Eyepiece focal length 15mm Eyepiece relief distance 45mm Power supply 3V, 2AA...
