Operation Manual East European Mount Picatinny Mount NVS 10MG DAY/NIGHT VISION SCOPE 105 Sparks Ave., Toronto, ON, M2H 2S5, Canada...
Page 3
IMPORTANT INFORMATION READ PRIOR TO ACTIVATION You have just purchased a complicated electronic device. To operate it properly, please read this manual carefully. Here are some common Precautions that must be noted. NEVER expose the opened objective lens of an active unit in daylight (if operating in night mode).
TABLE OF CONTENTS DESCRIPTION..........1 DELIVERY SET ..........2 SPECIFICATIONS.......... 3 DESIGN............4 TOOLS AND ACCESSORIES......9 GENERAL INFORMATION ......10 Precautions..........10 General Instructions ......... 11 Mounting on weapon (Side Mount) ..14 Mounting on weapon (Weaver Mount) ..14 MAINTENANCE ..........
DESCRIPTION 1.1 The integrated day/night riflescope NVS 10MG is a day/night sight (hereinafter referred to as the sight) with the set of accessories. The sight is intended for aimed firing during daylight and at night, using large variety of weapons with side mounting or weaver mounting rail.
DELIVERY SET Quantity NVS 10MG Weaver or side fail mount Wrench / Screwdriver Battery Allen key Battery control module Soft cloth Rubber eye guard Case Operational manual Disguise cover...
Page 10
WARNING! Never operate your night vision device at daylight without the lens cover on! Never direct the lens to bright light! The functional device scheme is given on the figure 1 (see the Exhibit A). In daylight, the handle (5) is set into the position DAY, setting the switching mechanism into position (4a).
Page 11
During night and in dusk turn the handle (5) into position NIGHT. This sets the switching mechanism into position (4b), when the image intensifier A2 replaces the lens (3) in the aiming channel. Internal micro switcher SA2 is connected mechanically with the handle (5). Now, when you turn the switch SA1 into ON position, the power from batteries G1 and G2 is applied to the image intensifier A2.
Page 12
Two rechargeable or non-rechargeable batteries of AA type are organized in a battery pack (5), which is placed into the battery compartment (6) and closed by cover (7). To fix the cover (7), turn the latch (8) counter clockwise. The sight has following controls (see figure 2): ...
TOOLS AND ACCESSORIES Battery control module should be used for the field inspection of the batteries. It has four LEDs on the front panel. Numbers “1.1”, “1.2”, “1.3”, “1.4”, which are marked near the LEDs, indicate battery voltage in Volts.
GENERAL INFORMATION Precautions NEVER switch the handle day/night into the night position in a daytime without the light filter on the objective; NEVER aim the sight to the bright sources of light (flares, glowing automotive head lamp) when it is on; NEVER touch the optical components by hands.
6.2 General Instructions Prior to usage, be sure that you understand the sight controls and fixing mechanism. If the sight was in storage, clean optical components with napkin. Remove the lubricant from the metallic surfaces. In conditions that require high level of camouflage at night time, set the protected eyeshade on the sight in the following order: unclasp the clutch (15) (figure 2);...
Page 16
place the ON/OFF switch into the position OFF; Visibility decreases and / or disappears. Bright light sources (moon, projectors or headlights) may result in visibility degradation or even complete disappearance. If this happens move the scope away from the light source immediately. The image should be restored in within 2 minutes.
Page 17
Turn off the switch (10). In a daytime, set the DAY/NIGHT handle 9 into the position DAY, check that the switch (10) is in the OFF position, and then take the light filter (1) off the objective (2). In twilight, put the light filter (1) on the objective (2), turn on the switch (10), and set the DAY/NIGHT handle 9 into the position NIGHT.
6.3 Mounting on weapon (Side Mount) Mount the sight on the weapon in the following order: Adjust the mounting seat groove (figure 2) with the mount type “dovetail”; Move the sight forward up to the stop and fix it, turning the handle (23) forward up to the total fixation on the mount (18).
MAINTENANCE Keep the sight clean from the dust and dirt while operating. Surfaces of the optical components should be always clean. Clean the glass surfaces with flannel or cotton wool saturated with ethanol or special cleaning solvent to remove grease. Wind a bit of a cotton wool at the end of wooden spatula;...
TROUBLESHOOTING Problem Probable reasons Possible solutions There is no Power supply is Check the battery luminescence of discharged charge with battery image intensifier control module. screen Replace or recharge the battery if needed. Area image is The optics is dirty or Wipe the eyepiece blurred and faint covered with moisture...
STORAGE When preparing the unit for long-term storage, it is necessary to perform corrosion proofing with a special lubricant. Each 4 (four) years the lubricant should be renewed to fully protect the device from corrosion. During this operation the rest of previous lubricant coating should be removed, and all metal surfaces should be degreased by a cotton-wool cloth moistened in benzene.
Page 22
It’s allowed to store the units in transportation case at temperatures up to 70C (158 F) for not more than 10 hours. It is unacceptable to place the NVS 10MGs on the floor, near stoves and windows that let through direct sunrays. Presence of acid and alkaline vapour, as well as of other aggressive admixtures in the air is unacceptable.
WARRANTY NEWCON warrants this product against defects in material and workmanship for one year from the date of the original purchase. Longer warranty is available, subject to the terms of the specific sales contract. Should your Newcon product prove to be defective during this period, please deliver the product securely packaged in its original container or an equivalent, along with the proof of the original purchase date, to your Newcon Dealer.
Eastern Standard Time. At no time should equipment be sent back to Newcon without following the instructions of our technical support department. NEWCON OPTIK accepts no responsibility for unauthorized returns. To locate NEWCON Authorized Dealer call: Tel: (416) 663-6963 Fax: (416) 663-9065 Email: newconsales@newcon-optik.com...
ACCEPTANCE CERTIFICATE NIGHT VISION DEVICE NVS 10MG NVS 10MG serial number: _________________________________ Image Intensifier Tube serial number: ___________________ Complies with all technical specifications and has passed the inspection. Date of production: _________________________________ Quality Inspector: __________________________________ Quality Assurance Seal...
