Elmo Visual Presenter HV-5100XG Specifications

HV-5100XG
High-Resolution Visual Presenter
SPECIFICATIONS
Camera Image pick-up device 1/3" progressive scan CCD, 850,000 pixels
Effective pixels 1034 (H) x 779 (V)
Frame rate 20 frames/sec.
Resolution RGB output 600(H) x 600(V) TV lines
Video output 400(H) TV lines
Optics Zoom Powered ( with double speed function ), 18x Optical
Lens F2.8, f=4.7 to 84.6mm
Shooting area Max. 13 7/8" x 10 1/4" ( 350 x 260mm )
Min. 1 1/8" x 7/8" ( 30 x 23mm )
Focus Auto/Manual (powered)
Functions White balance Full-Auto/One-Push/Manual
Nega/Posi conversion Provided
Frame Accumulate Mode Provided
Edge enhancement Provided
Color/B&W selection Provided
Pause mode Provided
Digital zoom Provided (2x, Scroll)
Gamma adjustment Provided
OSD (on-screen display) Provided
Image save Internal ( x 8 )
Image rotation Provided ( 0°, 90°, 180°, 270°)
Down converter Provided
Interfaces Internal selection Int./RGB1/RGB2
Analog RGB output XGA (1024 x 768 @60Hz)
Video output Composite, S-Video
DC 12V output Provided
RGB input Provided ( x2 )
Mouse port Provided
PC interface RS-232C port Provided
USB port Provided
Lighting Upper lighting unit Provided ( twin fluorescent lamp )
Base light Provided
Others Accessories AC adapter, RGB cable, LCD monitor connection cable
Video cable, S-Video cable, USB cable, Instruction manual
IR remote control, Mouse, Utility software CD-ROM, Warranty card
Dimensions Setup 27 1/2" x 21 3/8" x 21 7/8" ( 697 x 542 x 555mm )
(W x D x H) Folded 15 3/4" x 21 3/8" x 7 1/8" ( 400 x 542 x 181mm )
Weight 21.6lbs (9.8Kg)
Application software Image Mate
TWAIN drive ( for Windows, Mac )
Power source AC 100 to 240V, 50/60Hz
NOTE: Design and specifications are subject to change without prior notice. Dimensions and weight are approximate.
PROFILE
All dimensions in inches(mm)
15 3/4＂(400)
27 1/2＂(697)
15 3/4＂(400)
Printed in Japan(A)12/2007
H V - 5 1 0 0 X G
High-Resolution Visual Presenter
18times 850,000 pixels
Optical Zoom Progressive
Scan CCD
F.A.M. Moving Picture
(Frame Accumulate Mode) Output 20
frames / sec.
