Instruction Manual

HI8417 - HI8519
HI8520 - HI8521
Microprocessor
Bench-top
pH Meters
These Instruments are in
h t t p : / / w w w . h a n n a i n s t . c o m
Compliance with the CE Directives

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HI8417 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hanna Instruments HI8417

Summary of Contents for Hanna Instruments HI8417

  • Page 1: Instruction Manual

    Instruction Manual HI8417 - HI8519 HI8520 - HI8521 Microprocessor Bench-top pH Meters These Instruments are in h t t p : / / w w w . h a n n a i n s t . c o m Compliance with the CE Directives...

  • Page 2: Table Of Contents

    Dear Customer, Thank you for choosing a Hanna Instruments Product. Please read this instruction manual carefully before using the instru- ment. This manual will provide you with all the necessary information for the correct use of the instrument, as well as a precise idea of its versatility in a wide range of applications.

  • Page 3: Preliminary Examination

    All defective items must be returned in the original packing with the supplied accessories. GENERAL DESCRIPTION HI8417, HI8519, HI8520 and HI8521 Hanna Instruments bench- top pH meters are designed for simplicity of use. They feature: large liquid crystal display (LCD), user friendly key- board, error codes to guide the user in calibration and troubleshooting and storage of calibration data even after the unit is shut off.
  • Page 4 HI8520 pH/°C meter automatically recognizes 3 standard calibration buffer values (4.01, 7.01 and 10.01 pH). HI8520 comes supplied with HI1332B plastic-body combination pH electrode, HI7669/2W temperature probe (with 1 meter/ 3.3' cable), 12VDC adapter (HI710005 or HI710006) and a dust cover. HI8521 pH/mV/°C meter automatically recognizes 3 standard cali- bration buffer values (4.01, 7.01 and 10.01 pH).

  • Page 5: Hi8417

    FUNCTIONAL DESCRIPTION & SPECIFICATIONS OF HI8417 THE FRONT PANEL OF HI8417 °C HI 8417 BUFFER VALUES 20°C °C 6,88 7,02 4,00 4,00 °C 9,22 10,05 ON / OFF To turn the instrument ON and OFF. (Warning: Push the OFF key before unplugging instrument. If unplugged before turned off, the meter's memory will be erased).
  • Page 6 THE REAR PANEL OF HI8417 TEMPERATURE DC POWER 12V to 20V PROBE COMBINED RECORDER pH or ORP REFERENCE 0-2 VOLT ELECTRODE RESET ELECTRODES 1. BNC socket for pH and ORP electrode. 2. Reference Jack socket for reference electrode. 3. RESET button. 4.
  • Page 7 instrument's power supply is disconnected before the meter is switched off. Press the RESET button and restart the entire operation. Power connection Plug the 12VDC adapter (HI710005 or HI710006) into the DC socket (#6). Note: Make sure the main line is protected by a fuse. Note: HI8417 uses a rechargeable battery to retain the pH calibra- tion data.

  • Page 8: Hi8519

    FUNCTIONAL DESCRIPTION & SPECIFICATIONS OF HI8519 THE FRONT PANEL OF HI8519 HI 8519 OFFSET SLOPE TEMPERATURE °C OFFSET SLOPE TEMPERATURE °C Temperature Buffer Values (pH) °C °F 4.01 7.01 10.01 4.01 7.13 10.32 4.00 7.07 10.18 °C 4.00 7.03 10.06 4.02 7.00 9.96...
  • Page 9 Electrode and probe connections For combination pH or ORP electrodes (with internal reference) plug the electrode's BNC to the socket provided (#1). For an electrode with a separate reference, connect the measuring electrode's BNC to the BNC socket (#1) and the reference electrode's jack to the socket provided (#2).

  • Page 10: Hi8520

    FUNCTIONAL DESCRIPTION & SPECIFICATIONS OF HI8520 THE FRONT PANEL OF HI8520 ERROR SYMBOLS Temperature Buffer Values (pH) E1: pH out of range °C °F 4.01 7.01 10.01 E2: °C out of range 4.01 7.13 10.32 °C 4.00 7.07 10.18 E4: wrong pH 7 4.00 7.03 10.06...
  • Page 11 off. Press the RESET button and restart the entire operation. Power connection Plug the 12VDC adapter (HI710005 or HI710006) into the socket on the back of the meter (#5). Note: Make sure the main line is protected by a fuse. Note: HI8520 uses a rechargeable battery to retain the pH calibra- tion data.

  • Page 12: Hi8521

    FUNCTIONAL DESCRIPTION & SPECIFICATIONS OF HI8521 THE FRONT PANEL OF HI8521 ERROR SYMBOLS Temperature Buffer Values (pH) E1: pH out of range °C °F 4.01 7.01 10.01 E2: °C out of range 4.01 7.13 10.32 °C 4.00 7.07 10.18 E3: mV out of range 4.00 7.03 10.06...
  • Page 13 instrument's power supply is disconnected before the meter is switched off. Press the RESET button and restart the entire operation. Power connection Plug the 12VDC adapter (HI710005 or HI710006) into the socket on the back of the meter (#5). Note: Make sure your main line is protected by a fuse. Note: HI8521 uses a rechargeable battery to retain the pH calibra- tion data.

  • Page 14: Operational Guide

    OPERATIONAL GUIDE TAKING PH MEASUREMENTS Connect the instrument to the 12VDC adapter (HI710005 or HI710006). Plug the adapter into the mains. Make sure that the instrument has been calibrated for pH before taking pH measurements (see page 18). For HI8519 only: •...
  • Page 15 • In HI8417 the temperature reading is also displayed on the left LCD. °C Note: the electrode should be submerged approximately 4 cm (1½") into the solution. If the temperature probe is used, it should be located as close to the pH electrode as possible. If measurements are taken in different samples successively, it is recommended that the electrode is rinsed thoroughly for better condi- tioning and to eliminate cross-contamination of the sample.
  • Page 16 °C TAKING ORP MEASUREMENTS HI8417, HI8519 and HI8521 have the capability to take ORP measurements, using an ORP electrode. Hanna Instruments offers a variety of ORP electrodes for this purpose (see page 35). Contact your Dealer for more information. Just as pH measurements allow the acidity or the alkalinity of a...
  • Page 17 For HI8417 and HI8521 • Connect the ORP electrode to the meter and submerge the tip (4 cm / 1½") into the sample to be tested. Note: ORP measurements are taken without temperature compensa- tion. • Press the pH/mV key (HI8417) or RANGE RANGE key (HI8521) once to enter the mV mode.

  • Page 18: Ph Calibration

    PH CALIBRATION IMPORTANT The instrument's pH range should be re-calibrated: • When the meter is new. • Whenever the pH electrode is replaced. • At least once a month. • After use in aggressive chemicals. • After cleaning procedure and changing the reference electrolyte. •...
  • Page 19 Procedure: • Switch the instrument on after connecting the pH electrode and the temperature probe. • Immerse the pH electrode and the ATC probe into a neutral pH buffer solution (pH 7.01 for technical buffers, or pH 6.86 for NBS buffers).

  • Page 20: Procedure For Hi8519

    • The meter automatically recognizes the buffer value and prompts for the second at "d2" or "t2" (= pH 4.01, acid) or "d3" or "t3" (pH 9.18 and pH10.01 respectively, alkaline). • Press the CON key to confirm the pH value. •...

  • Page 21: Procedure For Hi8520/Hi8521

    Procedure: • Switch the instrument on after connecting the pH electrode. • Rinse and immerse the pH electrode in pH 7.01 buffer and shake briefly. Wait 1 or 2 minutes for the reading to stabilize. • Note the temperature of the buffer solution using a ChecktempC or a glass thermometer (e.g.20°C).

  • Page 22: Cal. W/ Manual Temp. Compensation

    • Press the CAL key. The temperature compensated buffer value will be displayed e.g. if the buffer temperature is at 25°C, the display will show pH7.01. If the buffer temperature is at 20°C, display will show pH 7.03 (see page 23). If "E4"...

  • Page 23: Ph Values At Various Temperature

    PH VALUES AT VARIOUS TEMPERATURE Temperature has an effect on pH. The calibration buffer solutions are effected by temperature changes to a lesser degree than normal solutions. For manual temperature calibration (standard with HI 8519 or op- tional with HI 8417, HI 8520 and HI 8521) please refer to the following chart.

  • Page 24: Troubleshooting Guide

    TROUBLESHOOTING Symptoms are: Possible Solutions: The Problem is: The instrument does Replace the probe. A defective ATC Probe not work with the HI7669/2W probe (not HI8519) The meter fails to Replace the electrode and A defective pH electrode calibrate or gives repeat the pH calibration.

  • Page 25: Electrode Conditioning & Maintenance

    ELECTRODE CONDITIONING AND MAINTENANCE Reference Filling Hole Reference Filling Hole Sensitive Reference Wire Wire Sensitive Reference Wire Wire Reference Reference Junction Junction Glass Glass Bulb Bulb Plastic Body Glass Body pH Electrode pH Electrode Reference Reference Wire Wire Reference Reference Junction Junction Platinum or...
  • Page 26 For refillable electrodes: If the filling solution (electrolyte) is more than 2½ cm (1") below the fill hole, add HI 7082 or HI 8082 3.5M KCl Electrolyte Solution for double junction or HI 7071 or HI 8071 3.5M KCl+AgCl Electrolyte Solution for single junction electrodes.
  • Page 27 CLEANING PROCEDURE General Soak in Hanna HI 7061 or HI 8061 General Clean- ing Solution for approximately ½ hour. Removal of films, dirt or deposits on the membrane/junction: - Protein Soak in Hanna HI 7073 or HI 8073 Protein Cleaning Solution for 15 minutes.

  • Page 28: Temperature-Resistance Correlation

    TEMPERATURE-RESISTANCE CORRELATION The resistance of glass electrodes partially depends on the tempera- ture. The lower the temperature, the higher the resistance. It takes longer time for the reading to stabilize if the resistance is higher. In addition, the response time will suffer to a greater degree at tempera- tures below 10°C.
  • Page 29 High concentrations of sodium ions interfere with readings in alkaline solutions; the pH at which the interference starts to be significant depends upon the composition of the glass. This interference is the alkaline error and causes the pH to be underestimated. Hanna's glass formulations have the indicated characteristics.

  • Page 30: Accessories

    ACCESSORIES pH CALIBRATION SOLUTIONS HI 70004P pH 4.01 Buffer Sachets, 20mL, 25 pcs HI 70007P pH 7.01 Buffer Sachets, 20mL, 25 pcs HI 70010P pH 10.01 Buffer Sachets, 20mL, 25 pcs HI 7004L pH 4.01 Buffer Solution, 460 mL HI 7006L pH 6.86 Buffer Solution, 460 mL HI 7007L pH 7.01 Buffer Solution, 460 mL...
  • Page 31 HI 7082 3.5M KCl Electrolyte, 4x50 mL, for double junction electrodes REFILL ELECTROLYTE SOLUTIONS IN FDA APPROVED BOTTLES HI 8071 3.5M KCl + AgCl Electrolyte, 4x50mL, for single junction electrodes HI 8072 1M KNO Electrolyte, 4x50 mL HI 8082 3.5M KCl Electrolyte, 4x50 mL, for double junction electrodes ORP PRETREATMENT SOLUTIONS HI 7091L...
  • Page 32 HI 1083B Glass-body, micro, Viscolene, non-refillable, combination pH elec- trode. Use: biotechnology, micro titration. 12 mm 5 mm 3 mm 0.5" 0.2" 3.0 mm DIA 0.12" 0.12" HI 1083 120 mm 4.7" HI 1131B Glass-body, single junction, refillable, combination pH electrode. Use: general purpose.
  • Page 33 HI 2031B Glass-body, semimicro, conic, refillable, combination pH electrode. Use: semisolid products. 6 mm 0.25" HI 2031 75 mm 2.95" "S" VERSION HI 1332B Plastic-body (Ultem ® ), double junction, refillable, combination pH electrode. Use: general purpose. 12 mm 0.5" HI 1332 120 mm "S"...
  • Page 34 FC 210B Glass-body, double junction, conic, Viscolene, non-refillable, combi- nation pH electrode. Use: milk, yogurt. 12 mm 0.5" FC 210 120 mm 4.7" FC 220B Glass-body, triple-ceramic, single junction, refillable, combination pH electrode. Use: food processing. 9.5mm DIA 12 mm 0.37"...
  • Page 35 ORP electrodes: HI 3131B Glass-body, refillable, combination platinum ORP electrode. Use: titration. 12 mm 0.5" HI 3131 150 mm "S" VERSION 5.9" HI 3230B Plastic-body (Ultem ® ), gel-filled, combination platinum ORP elec- trode. Use: general purpose. 12 mm 0.5" HI 3230 120 mm 4.7"...
  • Page 36 HI7855/10 Extension cable 10m (33') long HI7855/15 Extension cable 15m (49.5') long Power Units: HI710005 Voltage adapter from 115 VAC to 12 VDC HI710006 Voltage adapter from 230 VAC to 12 VDC OTHER ACCESSORIES ChecktempC Pocket-size thermometer (range -50.0 to 150.0°C) HI 76405 Electrode holder HI 7669/2W Temperature probe with 1 m (3.3') screened cable (not...

  • Page 37: Electrode Application Reference Guide

    ELECTRODE APPLICATION REFERENCE GUIDE Application Electrodes 1. Aquarium HI 1332B, HI 1911B 2. Bath-water HI 1910B, HI 1130B 3. Beer HI 1131B 4. Bread HI 2031B, FC 200B 5. Cheese FC 200B 6. Dairy products FC 911B, FC 100B 7. Dirty water HI 1910B, HI 1912B 8.

  • Page 38: Warranty

    If the repair is not covered by the warranty, you will be notified of the charges incurred. If the instrument is to be returned to Hanna Instruments, first obtain a Returned Goods Authorization number from the Cus- tomer Service department and then send it with shipping costs prepaid.

  • Page 39: Ce Declaration Of Conformity

    CE DECLARATION OF CONFORMITY DECLARATION OF CONFORMITY Hanna Instruments Srl V.le delle industrie 12 35010 Ronchi di Villafranca (PD) ITALY herewith certify that the bench pH meters HI 8417 HI 8519 HI 8520 HI 8521 have been tested and found to be in compliance with the following regulations:...
  • Page 40 h t t p : / / w w w . h a n n a i n s t . c o m...
