Hanna Instruments HI 8010 Instruction Manual

Instruction Manual
HI 8010
Portable pH Meter
w w w . h a n n a i n s t . c o m
FUNCTIONAL DESCRIPTION
WARRANTY
This meter is warranted for two years against defects in workmanship and materials
when used for their intended purpose and maintained according to instructions. Elec-
trodes are warranted for six months. This warranty is limited to repair or replacement
free of charge. Damage due to accidents, misuse, tampering or lack of prescribed main-
tenance are not covered. If service is required, contact the dealer from whom you pur-
chased the instrument. If under warranty, report the model number, date of purchase,
serial number and the nature of the problem. If the repair is not covered by the war-
ranty, you will be notified of the charges incurred. If the instrument is to be returned to
Hanna Instruments, first obtain a Returned Goods Authorization Number from the Cus-
tomer Service department and then send it with shipment costs prepaid. When shipping
any instrument, make sure it is properly packaged for complete protection.
PRELIMINARY EXAMINATION
Remove the instrument from the packing material and examine it
carefully to make sure that no damage has occurred during ship-
ment. If noticeable damage is found, notify your dealer.
HI 8010 comes supplied complete with HI 1230B pH electrode, cali-
bration screwdriver, 1 x 9V battery and instructions.
Note: Save all packing material until you are sure that the instru-
ment functions correctly. Any defective items must be returned
in the original packing together with the supplied accessories.
SPECIFICATIONS
Range 0.00 to 14.00 pH
Resolution 0.01 pH
Accuracy ±0.01 pH
(@20°C/68°F)
Typical EMC Deviation ±0.05 pH
Calibration Manual, 2-point through trimmers
Temperature Manual, through trimmer
Compensation from 0 to 100°C (32 to 212°F)
Probe HI 1230B double junction, gel-filled,
pH electrode with BNC connector and 1 m cable (included)
Environment 0 to 50°C (32 to 122°F); RH max 95%
Power Supply 1 x 9V battery
approx. 100 hours of continuous use
Dimensions 185x82x53 mm (7.3x3.2x2.1'')
Weight 265 g (9.3 oz.)
HI 8010 is in compliance with the directives.
