Contents Safety alert symbol review ...........2 Install the lights and lens ..........19 Safety information and precautions ......3 Attach the manual release rope and handle....19 Testing your garage door for binding & balance ..3 Fasten the door bracket (sectional door)....20 Hardware supplied ............3 Fasten the door bracket (one-piece door)....21 Carton inventory ............4 Connect door arm to trolley (sectional door)....22... -
Page 3: Safety Information And Precautions
Safety Information and Precautions To avoid damage to the garage door and opener, disable An unbalanced gara ge door might not re verse when required and someone under the door could be seriously locks before installing and operating the opener. Use a injured or killed. -
Page 5: Illustration Of Sectional Door Installation
Before you begin, survey your garage area to see whether any of the conditions below apply to your installation. SECTIONAL Door or FINISHED CEILING ONE-PIECE Door with Track Installation Support bracket & fastening hardware is required. Horizontal and vertical reinforcement See page 13. -
Page 6: Assembly Section: Pages
Assembly Section: Pages 6 - 7 ASSEMBLY STEP 1 Fasten the Rail To the Power Unit NOTE: To aid in assembly and installation, replace the foam packing around the power unit. Remove it after Installation Step 5. • Working on a level surface, align the rail assembly with the power unit, as shown. -
Page 7: Attach The Rail Brackets
ASSEMBLY STEP 3 Attach the Rail Brackets 1/4"-20 • Align rail brackets to end of rail assembly, as shown. Rail Lock Nuts Brackets • Insert two 1/4"-20 x 5/8" hex screws and lock nuts. Tighten securely with a 7/16" socket. Hardware Shown Actual Size 1/4"... -
Page 8: Installation Section: Pages
Installation Section: Pages 8 – 23 Installation Step 1 WARNING Determine Header Bracket Location If the header bracket is not rigidly fastened to a Installation procedures vary according to garage structural support on the header wall or ceiling, the door types. Follow the instructions which apply to safety reverse system may not work properly (see page your door. -
Page 9: One-Piece Door
ONE-PIECE Door Without Track Read the Safety Instructions on page 8. They also apply to doors without tracks. Unfinished • Close the door and mark the inside Header Wall Ceiling Vertical vertical centerline of your garage Centerline door. Extend the line onto the header wall above door. -
Page 10: Install The Header Bracket
You can attach the header bracket either to the wall Installation Step 2 above the garage door, or to the ceiling. Follow the instructions which will work best for your particular Install the Header Bracket requirements. Fastening the Header Bracket to the Ceiling Fastening the Header Bracket to the Wall •... -
Page 11: Attach The Rail To The Header Bracket
Installation Step 3 Attach the Rail to the Header Bracket • Position the opener on the garage floor below the header bracket. Use packing material as a protective base. If the door spring is in the way you’ll need help. Have someone hold the opener securely on a temporary support to allow the rail to clear the spring. -
Page 12: The Protector System
The Protector System ® Information you'll need before you begin the installation of the safety reversing sensor The safety reversing sensor must be connected and WARNING aligned correctly before the garage door opener will move in the down direction. This is a required safety device and cannot be disabled. -
Page 13: Install The Safety Reversing Sensor
Figure 1 Installation Step 4 Garage WALL or DOOR TRACK Installation Install the Safety Reversing Sensor (Receiving and Sending Eyes) Mounting Bracket With Square Holes "C" Wrap #10-32x3/8" Figures 1, 2 and 3 show recommended assembly of Screws bracket(s) and "C" wrap based on the wall installation of #10 - 32 Lock Nuts the sensors on each side of the garage door as shown on... -
Page 15: Position The Opener
Installation Step 5 CAUTION Position the Opener To prevent damage to steel, aluminum, fiberglass or Follow instructions which apply to your door glass panel doors, do not rest the opener on the door type as illustrated. without using a 2x4. SECTIONAL Door or ONE-PIECE Door with Track A 2x4 laid flat is convenient for setting an ideal door-... -
Page 16: Hang The Opener
Installation Step 6 WARNING Hang the Opener The opener could fall and injure someone if it is not properly secured. Fasten the opener securely to structural supports of the garage. Two representative installations are shown. Yours may be different. Hanging brackets should be angled, Figure 1, to provide rigid support. -
Page 17: Install The Door Control And Connect All Wires
Installation Step 7 WARNING Install the Door Control and Connect all Wiring Children operating or playing with a garage door opener can injure themselves or others. The garage door could close and cause serious injury or death. Install the door Install Door Control control (or any additional push buttons) out of the reach Locate the door control within sight of the door at a... -
Page 18: Electrical Requirements
Installation Step 8 WARNING Electrical Requirements To prevent electrocution or fire, installation and wiring must be in compliance with local electrical and building To reduce the risk of electric shock, your garage door codes. opener has a grounding type plug with a third grounding Do NOT use an extension cord, 2-wire adapter, or change pin. -
Page 19: Install The Lights And Lens
Installation Step 10 Install the Lights and Lens 100 Watt Max. Light Bulb • Install a 100 watt maximum light bulb in each socket. The lights will turn ON and remain lit for approximately 4-1/2 minutes when power is connected. Top Lens Slot Then the lights will turn OFF. -
Page 20: Fasten The Door Bracket (Sectional Door)
Installation Step 12 Fasten Door Bracket To prevent damage to steel, alumin um, fiberglass or Follow instructions which apply to your door type glass panel doors, always reinforce the inside of the door as illustrated below or on page 21. both vertically and horizontally with an angle iron. -
Page 21: Fasten The Door Bracket (One-Piece Door)
All ONE-PIECE Door Installation Procedure Please read and comply with the warnings and reinforcement instructions on page 20. They apply to one-piece doors also. • Center the bracket on the top of the door, in line with the header bracket as shown. Mark holes. Hardware Shown Actual Size •... -
Page 22: Connect Door Arm To Trolley (Sectional Door)
Installation Step 13 Connect Door Arm to Trolley Follow instructions which apply to your door type as illustrated below and on page 23. SECTIONAL Doors Only Make sure garage door is fully closed. Pull the emergency release handle to disconnect the outer trolley from the inner trolley. -
Page 23: Connect Door Arm To Trolley (One-Piece Door)
All ONE-PIECE Doors Assemble the Door Arm: • Fasten the straight and curved door arm sections together to the longest possible length (with a 2 or 3 hole overlap). • With the door closed, connect the straight door arm section to the door bracket with the 5/16"x1-1/4" clevis pin. -
Page 24: Adjustment Section: Pages
Adjustment Section: Pages 24 – 26 Adjustment Step 1 WARNING Adjust the UP and DOWN Limits Improper adjustment of the travel limits will interfere with Do not make any limit adjustments until the safety the proper operation of the safety reverse system. The reversing sensors are completely installed. -
Page 25: Force Adjustments
Adjustment Step 2 WARNING Adjust the Force Too much force on the door will interfere with the proper operation of the safety reverse system. The door might Force adjustment controls are located on the right panel not reverse properly when required and could seriously of the opener. -
Page 26: Test The Protector System
Adjustment Step 3 WARNING Test The Protector System ® Without a properly working safety reversing sensor, persons (particularly children) could be seriously injured • Press the remote control push button to open the door. or killed if trapped by a closing garage door. Repeat this •... -
Page 27: Operation Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING WARNING To reduce the risk of severe injury or death to persons: 1. READ AND FOLLOW ALL INSTRUCTIONS. 2. Do not permit children either to operate or to play with the opener. Keep remote control in a location inaccessible to children. -
Page 28: Operation Of Your Opener
Operation of Your Opener Activate the opener with any of the following: WARNING • The Remote Control Transmitter. Hold push button down until the door starts to move. • The Door Control. Hold push bar or button down Weak or broken springs could allow an open door to fall until the door starts to move. -
Page 30: Having A Problem
Having a Problem? Situation Probable Cause & Solution 1. Does the opener have electric power? Plug a lamp into the outlet. If it doesn't light, check the The opener doesn't fuse box or the circuit breaker. (Some outlets are controlled by a wall switch.) operate from either the door control or 2. - Page 31 Having a Problem? (continued) Situation Probable Cause & Solution The door opens but 1. If the opener lights blink, check the safety reversing sensor. See page 18. won't close: 2. If the opener lights do not blink and it is a new installation, check the down force. See Adjustment Step 2, page 25.
-
Page 34: Accessories
Accessories Available For Your Opener Model 1702LM Outside Quick Release: Model 81LM “Smart” Remote Control: Required for a garage with NO access Includes visor clip. door. Enables homeowner to open garage door manually from outside by disengaging trolley. Model 60LM Outside Keylock: Model 82LM 2-Channel “Smart”... -
Page 35: Index
Index Access Door/Outside Quick Release Accessory ......................31, 34 Electrical Safety Warnings ............................7, 18, 27 Garage Door Testing for balance, binding and sticking.........................3, 24, 27 Determining high point of travel: Sectional door..................................8 One-piece door ..................................9 Disabling existing locks ..............................3, 7 Force controls Adjustment procedures..............................25 Problems that might require force adjustments......................30, 31 Safety warnings .................................25, 27...
