Part 2: Class 579: Installation instructions
Items supplied . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.
2.
General and shipping braces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.
3.1
Adjusting the working height. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.2
Attaching the yarn stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.3
aligning and connecting the pedal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4.
Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
5.
5.1
Connecting the maintenance unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
5.2
Setting the operating pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6.
6.1
Filling the oil reservoirs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
7.
Sewing test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
page:
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 579 and is the answer not in the manual?

Questions and answers

Related Manuals for Duerkopp Adler 579

Summary of Contents for Duerkopp Adler 579

  • Page 1: Table Of Contents

    Contents page: Part 2: Class 579: Installation instructions Items supplied ..........3 General and shipping braces .

  • Page 3: Items Supplied

    Items supplied What items are supplied depends on your order. Prior to installation please check that all the required parts are present. 1 head – 2 operating panel – 3 stand – 4 pedal linkage – 5 pedal – 6 yarn stand –...

  • Page 4: Installing The Machine

    Installing the machine Adjusting the working height The working height is continuously adjustable between 85 and 120 cm (measured to the upper edge of the table plate). Undo locking screws 1 and 2 on both sides of the stand. – Adjust the table of the machine to the required working height.

  • Page 5: Aligning And Connecting The Pedal

    Aligning and connecting the pedal Align the pedal 4 laterally on the stand brace 5 so that the middle – of the pedal is roughly beneath the needle. Screw the pedal 4 firmly to the stand brace. – Screw the set value initiator 1 firmly to the stand brace. –...

  • Page 6: Electrical Connection

    Electrical connection CAUTION: The mains voltage must coincide with the rated voltage specified on the name plate. The machine adapts the local mains voltage via connection terminals 1 to 5 and A to D of the transformers in the control box. Both the transformer terminals are factory-set to a mains voltage of 230 V.

  • Page 7: Pneumatic Connection Connecting The Maintenance Unit

    Pneumatic connection Connecting the maintenance unit The pneumatic system of the machine and its auxiliary equipment must be supplied with compressed air containing absolutely no water or oil. CAUTION: For the pneumatic control processes to function properly the compressed-air supply must be able to provide air at a pressure of 6 ±...

  • Page 8: Lubrication

    Lubrication Caution: danger of injury Oil can cause skin eruptions. Avoid protracted contact with the skin. In the event of contact, thoroughly wash the affected area. CAUTION: The handling and disposal of mineral oils is subject to legal regulation. Deliver used oil to an authorised collection point. Protect your environment.

  • Page 9: Sewing Test

    Sewing test A sewing test must be carried out when setting-up is complete. Insert the mains plug. – Caution: danger of injury Turn off the main switch. The needle, looper and gimp threads may only be threaded with the sewing machine switched off. Thread the looper thread (see Operating instructions).
