Frigidaire FRT18LN5B Factory Parts Catalog
Top mount refrigerator
Hide thumbs
Also See for FRT18LN5B:
- Factory parts catalog (13 pages) ,
- Factory parts catalog (13 pages) ,
- Factory parts catalog (13 pages)
Advertisement
Quick Links
PRODUCT NO.
BASE MODEL NO.
FRT18LN5BQ3
FRT18LN5B
FRT18LN5BQ5
FRT18LN5B
FRT18LN5BW3
FRT18LN5B
FRT18LN5BW5
FRT18LN5B
MARKET
North America
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a System
bisque
R134a System
bisque
R134a System
white
R134a System
white
Publication No.
5995398814
031113
-EN/SERVICE/KHB
357
VOLTS
115
115
115
115
©2003 Electrolux Home Products, Inc.
All rights reserved
Advertisement
Related Manuals for Frigidaire FRT18LN5B
Summary of Contents for Frigidaire FRT18LN5B
- Page 1 PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT18LN5BQ3 FRT18LN5B R134a System bisque FRT18LN5BQ5 FRT18LN5B R134a System bisque FRT18LN5BW3 FRT18LN5B R134a System white FRT18LN5BW5 FRT18LN5B R134a System white MARKET North America ELECTROLUX HOME PRODUCTS, INC P.O. Box 212378, Augusta, GA 30917 Publication No.
- Page 2 Publication No. FRT18LN5B 5995398814 DOOR 11/03...
- Page 3 FRT18LN5B Publication No. 5995398814 DOOR A = FRT18LN5B (FRT18LN5BQ3) B = FRT18LN5B (FRT18LN5BQ5) C = FRT18LN5B (FRT18LN5BW3) D = FRT18LN5B (FRT18LN5BW5) POS. NO PART NO DESCRIPTION 240514605 A B C D Gasket,frzr door seal ,white ,magnetic 240514608 A B C D Gasket,seal ,white ,refr door ,magnetic 240337703 A B C D...
- Page 4 Publication No. FRT18LN5B 5995398814 CABINET 11/03...
- Page 5 FRT18LN5B Publication No. 5995398814 CABINET A = FRT18LN5B (FRT18LN5BQ3) B = FRT18LN5B (FRT18LN5BQ5) C = FRT18LN5B (FRT18LN5BW3) D = FRT18LN5B (FRT18LN5BW5) POS. NO PART NO DESCRIPTION 240355401 A B C D Cover-fan 240367001 A B C D Knob-damper control 5303001028 A B C D Nut,push-on 240367401...
- Page 6 Publication No. FRT18LN5B 5995398814 SHELVES 11/03...
- Page 7 FRT18LN5B Publication No. 5995398814 SHELVES A = FRT18LN5B (FRT18LN5BQ3) B = FRT18LN5B (FRT18LN5BQ5) C = FRT18LN5B (FRT18LN5BW3) D = FRT18LN5B (FRT18LN5BW5) POS. NO PART NO DESCRIPTION 240358002 A B C D Shelf-freezer,full width 5303299664 A B C D Spacer,shelf 240545001 A B C D Diffuser,air ,top 240362601...
- Page 8 Publication No. FRT18LN5B 5995398814 SYSTEM 11/03...
- Page 9 FRT18LN5B Publication No. 5995398814 SYSTEM A = FRT18LN5B (FRT18LN5BQ3) B = FRT18LN5B (FRT18LN5BQ5) C = FRT18LN5B (FRT18LN5BW3) D = FRT18LN5B (FRT18LN5BW5) POS. NO PART NO DESCRIPTION 240444401 A B C D Condenser,dynamic 218944001 A B C D Drier-filter,R134a System 240581701 A B C D Harness-wiring,machine compt 6* #...
-
Page 10: Ice Maker
Publication No. FRT18LN5B 5995398814 ICE MAKER 11/03... - Page 11 FRT18LN5B Publication No. 5995398814 ICE MAKER A = FRT18LN5B (FRT18LN5BQ3) B = FRT18LN5B (FRT18LN5BQ5) C = FRT18LN5B (FRT18LN5BW3) D = FRT18LN5B (FRT18LN5BW5) POS. NO PART NO DESCRIPTION 218976903 A B C D Tube-water inlet,inlet valve ,to filter 5304420650 A B C D Spring,shut-off arm 3206299 A B C D...
-
Page 12: Wiring Schematic
Publication No. FRT18LN5B 5995398814 WIRING SCHEMATIC 11/03... -
Page 13: Wiring Diagram
FRT18LN5B Publication No. 5995398814 WIRING DIAGRAM # = Fast-moving Parts 11/03 * = Non-Illustrated Parts...
