PRODUCT NO.
BASE MODEL NO.
FRT18LR7AQ4
FRT18LR7A
FRT18LR7AW4
FRT18LR7A
MARKET
North America
ENERGY GUIDE - 240465028
OWNER'S GUIDE - 240400106
SERVICE DATA SHEET - # 240379007
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque
R134a
white
Publication No.
5995375473
020708
-EN/SERVICE/DCS
390
FACTORY
PARTS CATALO
VOLTS
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18LR7A
©2002 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FRT18LR7A
Summary of Contents for Frigidaire FRT18LR7A
- Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT18LR7AQ4 FRT18LR7A R134a bisque FRT18LR7AW4 FRT18LR7A R134a white MARKET North America ENERGY GUIDE - 240465028 OWNER’S GUIDE - 240400106 SERVICE DATA SHEET - # 240379007 TOP MOUNT REFRIGERATOR Model No. ELECTROLUX HOME PRODUCTS, INC FRT18LR7A P.O.
- Page 2 Publication No. FRT18LR7A 5995375473 DOOR 07/02...
- Page 3 FRT18LR7A Publication No. 5995375473 DOOR A = FRT18LR7A (FRT18LR7AQ4) B = FRT18LR7A (FRT18LR7AW4) POS. NO PART NO DESCRIPTION 240542103 Gasket-frzr door,white ,magnetic 240542106 Gasket-refr door,white ,magnetic 240338303 Door,dairy ,clear 240381302 Plug-button,bisque ,hinge brg hole ,(2) 240381301 Plug-button,white ,hinge brg hole ,(2) 240409902 Panel-frzr door,bisque ,complete assy 240409901...
- Page 4 Publication No. FRT18LR7A 5995375473 CABINET 07/02...
- Page 5 FRT18LR7A Publication No. 5995375473 CABINET A = FRT18LR7A (FRT18LR7AQ4) B = FRT18LR7A (FRT18LR7AW4) POS. NO PART NO DESCRIPTION 240355401 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240462008 Cover-evap coil 240532102 Seal-coil cover...
- Page 6 Publication No. FRT18LR7A 5995375473 SHELVES 07/02...
- Page 7 FRT18LR7A Publication No. 5995375473 SHELVES A = FRT18LR7A (FRT18LR7AQ4) B = FRT18LR7A (FRT18LR7AW4) POS. NO PART NO DESCRIPTION 240358002 Shelf-freezer,full width 5303299664 Spacer,shelf 240545001 Diffuser,air ,top 240362601 Diffuser,air ,bottom 14 # 240505801 Switch,light/lamp 240436702 Light Bulb, A-15, clear, 40 W, 120 V, miniature 241500701 Socket-light/lamp 240352701...
- Page 8 Publication No. FRT18LR7A 5995375473 SYSTEM 07/02...
- Page 9 FRT18LR7A Publication No. 5995375473 SYSTEM A = FRT18LR7A (FRT18LR7AQ4) B = FRT18LR7A (FRT18LR7AW4) POS. NO PART NO DESCRIPTION 240444401 Condenser,dynamic 218944001 Drier-filter,R134a System 240496101 Wiring Harness, machine compt, w/electric cord 6* # 240375501 Wiring Harness,control box 6* # 240524701 Wiring Harness,freezer section 14 # 5303918208 Defrost Heater Kit...
-
Page 10: Ice Maker
Publication No. FRT18LR7A 5995375473 ICE MAKER 07/02... - Page 11 FRT18LR7A Publication No. 5995375473 ICE MAKER A = FRT18LR7A (FRT18LR7AQ4) B = FRT18LR7A (FRT18LR7AW4) POS. NO PART NO DESCRIPTION 218976901 Tube-water inlet, inlet valve to ice maker 5304420650 Spring,shut-off arm 5308000039 Screw,hex wshr hd, 8-32CA x 0.500, serrated head 3206299 Label,ID plate 3206301 Gear...
-
Page 12: Wiring Schematic
Publication No. FRT18LR7A 5995375473 WIRING SCHEMATIC 07/02... -
Page 13: Wiring Diagram
FRT18LR7A Publication No. 5995375473 WIRING DIAGRAM # = Fast-moving Parts 07/02 * = Non-Illustrated Parts...
