PRODUCT NO.
BASE MODEL NO.
FRT18LR7AQ2
FRT18LR7A
FRT18LR7AW2
FRT18LR7A
MARKET
North America
WIRING DIAGRAM - 240379007
OWNER'S GUIDE - 240400105
SERVICE DATA SHEET - # 240379007
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque
R134a
white
Publication No.
5995366118
020218
-EN/SERVICE/DCS
390
FACTORY
PARTS CATALO
VOLTS
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18LR7A
©2001 White Consolidated Industries, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FRT18LR7A
Summary of Contents for Frigidaire FRT18LR7A
- Page 1 PRODUCT NO. BASE MODEL NO. FRT18LR7AQ2 FRT18LR7A FRT18LR7AW2 FRT18LR7A MARKET North America WIRING DIAGRAM - 240379007 OWNER’S GUIDE - 240400105 SERVICE DATA SHEET - # 240379007 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O. Box 212378, Augusta, GA 30917 SERIES COLOR R134a...
- Page 2 Publication No. FRT18LR7A 5995366118 DOOR 02/02...
- Page 3 A = FRT18LR7A (FRT18LR7AQ2) B = FRT18LR7A (FRT18LR7AW2) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRT18LR7A DOOR PART NO DESCRIPTION 240514605 Gasket-frzr door,white ,magnetic 240514606 Gasket-refr door,white ,magnetic 240338303 Door,dairy ,clear 240381302 Plug-button,bisque ,hinge brg hole ,(2)
- Page 4 Publication No. FRT18LR7A 5995366118 CABINET 02/02...
- Page 5 A = FRT18LR7A (FRT18LR7AQ2) B = FRT18LR7A (FRT18LR7AW2) POS. NO 10*# 13 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18LR7A CABINET PART NO DESCRIPTION 240355401 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan...
- Page 6 Publication No. FRT18LR7A 5995366118 SHELVES 02/02...
- Page 7 A = FRT18LR7A (FRT18LR7AQ2) B = FRT18LR7A (FRT18LR7AW2) POS. NO 14 # 17*# 21 # 23 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18LR7A SHELVES PART NO DESCRIPTION 240358002 Shelf-freezer,full width 5303299664 Spacer-shelf 240362502 Diffuser-air,top 240362601 Diffuser-air,bottom 240505801...
- Page 8 Publication No. FRT18LR7A 5995366118 SYSTEM 02/02...
- Page 9 A = FRT18LR7A (FRT18LR7AQ2) B = FRT18LR7A (FRT18LR7AW2) POS. NO 6* # 6* # 14 # 15 # 21 # 30 # 55 # 60 # 61 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18LR7A SYSTEM PART NO...
-
Page 10: Ice Maker
Publication No. FRT18LR7A 5995366118 ICE MAKER 02/02... - Page 11 A = FRT18LR7A (FRT18LR7AQ2) B = FRT18LR7A (FRT18LR7AW2) POS. NO 11 # 12 # 13 # 15 # 17 # 55 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18LR7A ICE MAKER PART NO DESCRIPTION 218976901 Tube-water inlet,inlet valve to ice maker...
-
Page 12: Wiring Schematic
Publication No. FRT18LR7A 5995366118 WIRING SCHEMATIC 02/02... -
Page 13: Wiring Diagram
FRT18LR7A Publication No. 5995366118 WIRING DIAGRAM # = Fast-moving Parts 02/02 * = Non-Illustrated Parts...
