Frigidaire FRT18FS5A Factory Parts Catalog
Top-mount refrigerator
Hide thumbs
Also See for FRT18FS5A:
- Factory parts catalog (13 pages) ,
- Factory parts catalog (13 pages)
Advertisement
Quick Links
PRODUCT NO.
BASE MODEL NO.
FRT18FS5AQ6
FRT18FS5A
FRT18FS5AW6
FRT18FS5A
MARKET
North America
WIRING DIAGRAM - 240379010
OWNER'S GUIDE - 240400108
SERVICE DATA SHEET - 240379010
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque
R134a
white
Publication No.
5995388583
030408
-EN/SERVICE /ECL
390
FACTORY
PARTS CATALO
VOLTS
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18FS5A
©2003 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FRT18FS5A
Summary of Contents for Frigidaire FRT18FS5A
- Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT18FS5AQ6 FRT18FS5A R134a bisque FRT18FS5AW6 FRT18FS5A R134a white MARKET North America WIRING DIAGRAM - 240379010 OWNER’S GUIDE - 240400108 SERVICE DATA SHEET - 240379010 TOP MOUNT REFRIGERATOR Model No. ELECTROLUX HOME PRODUCTS, INC FRT18FS5A P.O.
- Page 2 Publication No. FRT18FS5A 5995388583 DOOR 04/03...
- Page 3 FRT18FS5A Publication No. 5995388583 DOOR A = FRT18FS5A (FRT18FS5AW6) B = FRT18FS5A (FRT18FS5AQ6) POS. NO PART NO DESCRIPTION 240542103 Gasket-frzr door,white ,magnetic 240542106 Gasket-refr door,white ,magnetic 240337703 Door-dairy,w/o graphics ,clear 240381301 Plug-button,white ,hinge brg hole ,(2) 240381302 Plug-button,bisque ,hinge brg hole ,(2) 240410201 Door-frzr,white ,complete assy 240410202...
- Page 4 Publication No. FRT18FS5A 5995388583 CABINET 04/03...
- Page 5 FRT18FS5A Publication No. 5995388583 CABINET A = FRT18FS5A (FRT18FS5AW6) B = FRT18FS5A (FRT18FS5AQ6) POS. NO PART NO DESCRIPTION 240355401 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240462008 Cover-evap coil 10*# 240524701...
- Page 6 Publication No. FRT18FS5A 5995388583 SHELVES 04/03...
- Page 7 FRT18FS5A Publication No. 5995388583 SHELVES A = FRT18FS5A (FRT18FS5AW6) B = FRT18FS5A (FRT18FS5AQ6) POS. NO PART NO DESCRIPTION 240358002 Shelf-freezer,full width 5303299664 Spacer,shelf 240545001 Diffuser,air ,top 240362601 Diffuser,air ,bottom 14 # 240505801 Switch,light/lamp 240436702 Light Bulb/Lamp,A-15 ,clear ,40 W ,120 V,miniature 241500701 Socket-light/lamp 240352701...
- Page 8 Publication No. FRT18FS5A 5995388583 SYSTEM 04/03...
- Page 9 FRT18FS5A Publication No. 5995388583 SYSTEM A = FRT18FS5A (FRT18FS5AW6) B = FRT18FS5A (FRT18FS5AQ6) POS. NO PART NO DESCRIPTION 240444401 Condenser,dynamic 218944001 Drier-filter,R134a System 240496101 Wiring Harness,machine compt ,w/electric cord 6* # 240388701 Wiring Harness,control box 6* # 240524701 Wiring Harness,freezer section 14 # 5303918208 Defrost Heater Kit...
-
Page 10: Ice Maker
Publication No. FRT18FS5A 5995388583 ICE MAKER 04/03... - Page 11 FRT18FS5A Publication No. 5995388583 ICE MAKER A = FRT18FS5A (FRT18FS5AW6) B = FRT18FS5A (FRT18FS5AQ6) POS. NO PART NO DESCRIPTION 218976901 Tube-water inlet,inlet valve ,to ice maker 5304420650 Spring,shut-off arm 3206299 Label,ID plate 3206301 Gear 3206303 Plate-mounting 3206305 Screw-ground wire,8-32 x 0.250 3206306 Motor-ice maker 3206312...
-
Page 12: Wiring Schematic
Publication No. FRT18FS5A 5995388583 WIRING SCHEMATIC 04/03... -
Page 13: Wiring Diagram
FRT18FS5A Publication No. 5995388583 WIRING DIAGRAM # = Fast-moving Parts 04/03 * = Non-Illustrated Parts...
