Frigidaire FRT18LN5B Factory Parts Catalog
Top mount refrigerator
Hide thumbs
Also See for FRT18LN5B:
- Factory parts catalog (13 pages) ,
- Factory parts catalog (13 pages) ,
- Factory parts catalog (13 pages)
Advertisement
Quick Links
PRODUCT NO.
BASE MODEL NO.
FRT18LN5BQ0
FRT18LN5B
FRT18LN5BW0
FRT18LN5B
MARKET
North America
OWNER'S GUIDE - 240400105
SERVICE DATA SHEET - 240379007
WIRING DIAGRAM - 240379007
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a System
bisque
R134a System
white
Publication No.
5995370029
020415
-EN/SERVICE /MLR
924 / 05
FACTORY
PARTS CATALO
VOLTS
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18LN5B
©2002 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRT18LN5B
Summary of Contents for Frigidaire FRT18LN5B
- Page 1 PRODUCT NO. BASE MODEL NO. FRT18LN5BQ0 FRT18LN5B FRT18LN5BW0 FRT18LN5B MARKET North America OWNER’S GUIDE - 240400105 SERVICE DATA SHEET - 240379007 WIRING DIAGRAM - 240379007 ELECTROLUX HOME PRODUCTS, INC P.O. Box 212378, Augusta, GA 30917 SERIES COLOR R134a System bisque...
- Page 2 Publication No. FRT18LN5B 5995370029 DOOR 04/02...
- Page 3 A = FRT18LN5B (FRT18LN5BQ0) B = FRT18LN5B (FRT18LN5BW0) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRT18LN5B DOOR PART NO DESCRIPTION 240514605 Gasket-frzr door,white ,magnetic 240514606 Gasket-refr door,white ,magnetic 240311502 Support-door rack,2 liter ,RH 240311501 Support-door rack,2 liter ,LH...
- Page 4 Publication No. FRT18LN5B 5995370029 CABINET 04/02...
- Page 5 A = FRT18LN5B (FRT18LN5BQ0) B = FRT18LN5B (FRT18LN5BW0) POS. NO 10 # 13 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18LN5B CABINET PART NO DESCRIPTION 240355401 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan...
- Page 6 Publication No. FRT18LN5B 5995370029 SHELVES 04/02...
- Page 7 A = FRT18LN5B (FRT18LN5BQ0) B = FRT18LN5B (FRT18LN5BW0) POS. NO 14 # 17 # 21 # 23 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18LN5B SHELVES PART NO DESCRIPTION 240358002 Shelf-freezer,full width 5303299664 Spacer,shelf 240362502 Diffuser,air ,top 240362601...
- Page 8 Publication No. FRT18LN5B 5995370029 SYSTEM 04/02...
- Page 9 A = FRT18LN5B (FRT18LN5BQ0) B = FRT18LN5B (FRT18LN5BW0) POS. NO 6* # 6* # 14 # 15 # 21 # 29 # 30 # 55 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18LN5B SYSTEM PART NO DESCRIPTION 240406404...
-
Page 10: Ice Maker
Publication No. FRT18LN5B 5995370029 ICE MAKER 04/02... - Page 11 A = FRT18LN5B (FRT18LN5BQ0) B = FRT18LN5B (FRT18LN5BW0) POS. NO 11 # 12 # 13 # 15 # 17 # 55 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18LN5B ICE MAKER PART NO DESCRIPTION 218976901 Tube-water inlet,inlet valve ,to ice maker...
-
Page 12: Wiring Schematic
Publication No. FRT18LN5B 5995370029 WIRING SCHEMATIC 04/02... -
Page 13: Wiring Diagram
FRT18LN5B Publication No. 5995370029 WIRING DIAGRAM # = Fast-moving Parts 04/02 * = Non-Illustrated Parts...
