PRODUCT NO.
BASE MODEL NO.
FRT18LBHW0
FRT18LBH
MARKET
North America
WIRING DIAGRAM - # 218758400
OWNER'S GUIDE - # 218942600
SERVICE DATA SHEET - # 218758400
101 MASTERS BLVD.
ANDERSON, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a System
white
Publication No.
5995324406
990604
-EN/SERVICE /KB
390
REFRIGERATOR
VOLTS
115
REFRIGERATOR
Model No.
FRT18LBH
©1999 White Consolidated Industries, Inc.
All rights reserved

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT18LBH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FRT18LBH

Summary of Contents for Frigidaire FRT18LBH

  • Page 1 FACTORY PARTS CATALOG REFRIGERATOR PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT18LBHW0 FRT18LBH R134a System white MARKET North America WIRING DIAGRAM - # 218758400 OWNER’S GUIDE - # 218942600 SERVICE DATA SHEET - # 218758400 REFRIGERATOR Model No. FRT18LBH 101 MASTERS BLVD.
  • Page 2 Publication No. FRT18LBHW0 5995324406 DOOR 06/99...
  • Page 3 FRT18LBHW0 Publication No. 5995324406 DOOR POS. NO PART NO DESCRIPTION 215608916 Gasket-frzr door,white ,magnetic 218730605 Gasket-refr door,white ,magnetic 218360701 Panel-inner door,refr 218758602 Support-door rack,RH/LH 5303304569 Door-dairy,12.96" wide 218763638 Rack-door,22.36" x 2.04" 218360101 Panel-inner door,frzr 5308000134 Plug-button,white ,hinge brg hole 5303917805 Panel-frzr door,white ,w/insulation 218917601 Label-nameplate,white...
  • Page 4 Publication No. FRT18LBHW0 5995324406 CABINET 06/99...
  • Page 5 FRT18LBHW0 Publication No. 5995324406 CABINET POS. NO PART NO DESCRIPTION 218672501 Cover-fan 5303307351 Knob-damper control 5303001028 Nut,push-on 218722200 Damper-fan cover,black 218649000 Fan Blade,black 218448301 Cover,white ,lwr hinge hole 5300157666 Bushing-motor mtg,(2) 5303205118 Bracket-motor mtg,front 3206451 Cover-evap coil 5303208309 Plug-hole,factory test 215079000 Plug-harness hole,round 215079100...
  • Page 6 Publication No. FRT18LBHW0 5995324406 SHELVES 06/99...
  • Page 7 FRT18LBHW0 Publication No. 5995324406 SHELVES POS. NO PART NO DESCRIPTION 218874301 Mullion,white 218781003 Heater-mullion 218845602 Tapping Plate,mullion mtg ,(2) 218814800 Panel-top,refr cavity 218872903 Divider,styrofoam ,w/foil tape 8* # 218878500 Harness-wiring,control/divider 218814700 Panel-bottom,frzr cavity 215667501 Tray-ice,plastic 5303288242 Shelf-freezer,fixed/flat ,full width, wire 5303299664 Spacer-shelf 218730000...
