Frigidaire FRT18KG3D Factory Parts Catalog
Top-mount refrigerator
Hide thumbs
Also See for FRT18KG3D:
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages)
Advertisement
Quick Links
N05L00004.eps N05DBDCKA0.eps N05BBAABA20.eps N05SAAAEF14.eps
N05CBBBAC1.eps
240398801.eps 240398601.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Product No.
FRT18KG3DW0
Series
R134a
Color
white
Volts
115
Wiring Diagram
240398801
Owner's Guide
240400111
Market
North America
Energy Guide
240598697
Service Data Sheet
240379015
Installation Instructions 240568300
Publication No.
5995412508
04/06/30
(EN/SERVICE/WC)
390
TOP-MOUNT
REFRIGERATOR
Model No.
FRT18KG3D
©
Copyright
2004 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Related Manuals for Frigidaire FRT18KG3D
Summary of Contents for Frigidaire FRT18KG3D
- Page 1 Volts Wiring Diagram 240398801 Owner's Guide 240400111 Market North America Energy Guide 240598697 Service Data Sheet 240379015 Installation Instructions 240568300 TOP-MOUNT REFRIGERATOR FRT18KG3D Publication No. 5995412508 04/06/30 (EN/SERVICE/WC) © Copyright 2004 Electrolux Home Products, Inc. Model No. All rights reserved.
- Page 2 Publication No: 5995412508 FRT18KG3DW0 DOOR 06/04...
- Page 3 POS. NO PART NO. 240542103 240542106 240534901 240534701 240337703 240534801 240381301 240410201 240415201 240312403 240312404 240494001 240410301 218428101 240383401 240521301 218252200 240527101 218396700 215503200 # Functional Parts * Non-Illustrated Parts FRT18KG3DW0 DOOR DESCRIPTION Gasket-frzr door, white, magnetic Gasket-refr door, white, magnetic Rack-door Rack-door, 4B Door-dairy, w/o graphics, clear...
- Page 4 Publication No: 5995412508 06/04 FRT18KG3DW0 CABINET N05BBAABA20...
- Page 5 POS. NO PART NO. 240355401 240367001 5303001028 241523701 5308000010 5300157666 5303292396 240462010 240568601 5303208309 241557601 218843800 240374401 12A* 241586701 13 # 240369701 215474201 218931001 5303292397 240433201 218252200 215774901 240335501 240314002 240311303 240313802 240336802 240516401 241591601 240313701 240354401 5303001609 5308009759 240423601 240335003 240516501 5303001343...
- Page 6 Publication No: 5995412508 06/04 FRT18KG3DW0 SHELVES N05SAAAEF14...
- Page 7 POS. NO PART NO. 215667501 240358002 5303299664 241542001 240362601 240371304 14 # 241554901 241555401 241559801 240352701 17*# 240388701 240568607 5308016567 240360801 21 # 5304421256 240468201 23 # 240371001 5303001259 240372409 240372410 240364713 240361202 240361301 240337103 240357704 240530803 240350620 240561502 240530601 240530701 240350608 5308016566...
- Page 8 Publication No: 5995412508 06/04 FRT18KG3DW0 SYSTEM N05CBBBAC1...
- Page 9 POS. NO PART NO. 240406408 240405201 5303208866 5308000296 218944001 240581601 241520701 6* # 240388701 6* # 240581801 14 # 5303918208 15 # 5303918274 5308000110 241551801 241551901 21 # 5303918202 240330001 218252200 218513300 240491501 240598501 5304434992 29 # 5303918297 30 # 5304433579 31 # 5304433578...
-
Page 10: Wiring Schematic
Publication No: 5995412508 FRT18KG3DW0 WIRING SCHEMATIC 06/04... -
Page 11: Wiring Diagram
FRT18KG3DW0 Publication No: 5995412508 WIRING DIAGRAM 06/04 # Functional Parts * Non-Illustrated Parts...
