Frigidaire FRT21P6C Factory Parts Catalog
Top mount refrigerator
Hide thumbs
Also See for FRT21P6C:
- Factory parts catalog (13 pages) ,
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages)
Advertisement
Quick Links
Download this manual
See also:
Factory Parts Catalog
PRODUCT NO.
BASE MODEL NO.
FRT21P6CSB1
FRT21P6CS
FRT21P6CSK1
FRT21P6CS
MARKET
North America
ENERGY GUIDE - 240572116
OWNER'S GUIDE - 240400109
SERVICE DATA SHEET - 240379012
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
stain/blk (RH)
R134a
stain/blk (LH)
Publication No.
5995398459
031106
-EN/SERVICE /DCS
357
FACTORY
PARTS CATALO
VOLTS
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT21P6C
©2003 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRT21P6C
Summary of Contents for Frigidaire FRT21P6C
- Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT21P6CSB1 FRT21P6CS R134a stain/blk (RH) FRT21P6CSK1 FRT21P6CS R134a stain/blk (LH) MARKET North America ENERGY GUIDE - 240572116 OWNER’S GUIDE - 240400109 SERVICE DATA SHEET - 240379012 TOP MOUNT REFRIGERATOR Model No.
- Page 2 Publication No. FRT21P6CS 5995398459 DOOR 11/03...
- Page 3 FRT21P6CS Publication No. 5995398459 DOOR A = FRT21P6CS (FRT21P6CSB1) B = FRT21P6CS (FRT21P6CSK1) POS. NO PART NO DESCRIPTION 240514611 Gasket,seal ,black ,frzr door ,magnetic 240514612 Gasket,seal ,black ,refr door ,magnetic 240337703 Door-dairy,w/o graphics ,clear 240450331 Door,frzr ,stainless steel ,RH 240450332 Door,frzr ,stainless steel ,LH 240415204 Label-nameplate,black...
- Page 4 Publication No. FRT21P6CS 5995398459 CABINET 11/03...
- Page 5 FRT21P6CS Publication No. 5995398459 CABINET A = FRT21P6CS (FRT21P6CSB1) B = FRT21P6CS (FRT21P6CSK1) POS. NO PART NO DESCRIPTION 240355402 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240313610 Cover-evap coil,w/o light 240568606 Seal-coil cover...
- Page 6 Publication No. FRT21P6CS 5995398459 SHELVES N05SAAAFE10 11/03...
- Page 7 FRT21P6CS Publication No. 5995398459 SHELVES A = FRT21P6CS (FRT21P6CSB1) B = FRT21P6CS (FRT21P6CSK1) POS. NO PART NO DESCRIPTION 215667501 Tray,ice cube ,plastic 240358003 Shelf,freezer ,full-width ,wire 240545901 Diffuser-air,top 240362601 Diffuser,air ,bottom 14 # 240505801 Switch,light/lamp 240436702 Light Bulb/Lamp,A-15 ,clear ,40 W ,120 V,miniature 241500701 Socket-light/lamp 240368101...
- Page 8 Publication No. FRT21P6CS 5995398459 SYSTEM 11/03...
- Page 9 FRT21P6CS Publication No. 5995398459 SYSTEM A = FRT21P6CS (FRT21P6CSB1) B = FRT21P6CS (FRT21P6CSK1) POS. NO PART NO DESCRIPTION 240444401 Condenser,dynamic 218944001 Drier-filter,R134a System 240581701 Harness-wiring,machine compt 6* # 240388701 Wiring Harness,control box 6* # 240524701 Wiring Harness,freezer section 6* # 240581801 Harness-wiring,compressor 14 #...
-
Page 10: Wiring Schematic
Publication No. FRT21P6CS 5995398459 WIRING SCHEMATIC 11/03... -
Page 11: Wiring Diagram
FRT21P6CS Publication No. 5995398459 WIRING DIAGRAM # = Fast-moving Parts 11/03 * = Non-Illustrated Parts...
