Frigidaire FRT21P6C Factory Parts Catalog
Top-mount refrigerator
Hide thumbs
Also See for FRT21P6C:
- Factory parts catalog (13 pages) ,
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages)
Advertisement
Quick Links
Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet
Installation Instructions 240568300
N05L00003.eps N05DCDBCA1.eps N05BBAABD0.eps N05SABAFE11.eps
N05CABBAB4.eps
240398801.eps 240398601.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
FRT21P6CQ3 FRT21P6CW3 FRT21P6CSB3 FRT21P6CSK3
R134a
R134a
R134a
bisque
white
stain/blk RH
115
115
115
240398801
240398801
240398801
240400111
240400111
240400111
North America North America North America North America
240598615
240598615
240572116
240379014
240379014
240379014
240568300
240568300
Publication No.
5995410858
04/06/02
(EN/SERVICE/DCS)
357
Copyright
R134a
stain/blk LH
115
240398801
240400111
240572116
240379014
240568300
TOP-MOUNT
REFRIGERATOR
Model No.
FRT21P6C /
FRT21P6CS
©
2004 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Related Manuals for Frigidaire FRT21P6C
Summary of Contents for Frigidaire FRT21P6C
- Page 1 North America North America North America North America 240598615 240598615 240572116 240379014 240379014 240379014 240568300 240568300 TOP-MOUNT REFRIGERATOR Model No. FRT21P6C / FRT21P6CS Publication No. 5995410858 04/06/02 (EN/SERVICE/DCS) © Copyright 2004 Electrolux Home Products, Inc. All rights reserved. R134a stain/blk LH...
- Page 2 Publication No: 5995410858 FRT21P6C / FRT21P6CS DOOR 06/04...
- Page 3 240527101 240527102 240338101 240337901 240338001 240495804 218490901 # Functional Parts * Non-Illustrated Parts FRT21P6C / FRT21P6CS DOOR A FRT21P6C (FRT21P6CQ3) B FRT21P6C (FRT21P6CW3) C FRT21P6CS (FRT21P6CSB3) D FRT21P6CS (FRT21P6CSK3) DESCRIPTION A B - - Gasket, seal, white, frzr door, magnetic...
- Page 4 Publication No: 5995410858 FRT21P6C / FRT21P6CS CABINET 06/04...
- Page 5 240354404 5303001609 5308009759 240578901 240335003 218233300 5303292395 218362500 # Functional Parts * Non-Illustrated Parts FRT21P6C / FRT21P6CS CABINET A FRT21P6C (FRT21P6CQ3) B FRT21P6C (FRT21P6CW3) C FRT21P6CS (FRT21P6CSB3) D FRT21P6CS (FRT21P6CSK3) DESCRIPTION A B C D Cover-fan A B C D...
- Page 6 Publication No: 5995410858 FRT21P6C / FRT21P6CS CABINET 06/04...
- Page 7 5303316859 240326115 241500301 216850900 5304414035 5303305324 5303305345 # Functional Parts * Non-Illustrated Parts FRT21P6C / FRT21P6CS CABINET A FRT21P6C (FRT21P6CQ3) B FRT21P6C (FRT21P6CW3) C FRT21P6CS (FRT21P6CSB3) D FRT21P6CS (FRT21P6CSK3) DESCRIPTION A B C D Pin-lower hinge A B C D Screw, hex washer head, 8-15A x 0.500...
- Page 8 Publication No: 5995410858 FRT21P6C / FRT21P6CS SHELVES 06/04...
- Page 9 240443318 240357802 240350654 5308016566 215005100 240598615 240572116 # Functional Parts * Non-Illustrated Parts FRT21P6C / FRT21P6CS SHELVES A FRT21P6C (FRT21P6CQ3) B FRT21P6C (FRT21P6CW3) C FRT21P6CS (FRT21P6CSB3) D FRT21P6CS (FRT21P6CSK3) DESCRIPTION A B C D Tray, ice cube, plastic A B C D...
- Page 10 Publication No: 5995410858 FRT21P6C / FRT21P6CS SYSTEM N05CABBAB4 06/04...
- Page 11 240524101 5304418225 5303316859 240493101 240409302 5303918210 5304421289 # Functional Parts * Non-Illustrated Parts FRT21P6C / FRT21P6CS SYSTEM A FRT21P6C (FRT21P6CQ3) B FRT21P6C (FRT21P6CW3) C FRT21P6CS (FRT21P6CSB3) D FRT21P6CS (FRT21P6CSK3) DESCRIPTION A B C D Condenser, dynamic A B C D...
-
Page 12: Wiring Schematic
Publication No: 5995410858 FRT21P6C / FRT21P6CS WIRING SCHEMATIC 06/04... -
Page 13: Wiring Diagram
FRT21P6C / FRT21P6CS Publication No: 5995410858 WIRING DIAGRAM 06/04 # Functional Parts * Non-Illustrated Parts...
