PRODUCT NO.
BASE MODEL NO.
FRT21P6BSB3
FRT21P6BS
MARKET
North America
ENERGY GUIDE - 218791411
OWNER'S GUIDE - 240400106
SERVICE DATA SHEET - 240379010
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
stain/blk
Publication No.
5995379657
021011
-EN/SERVICE/KHB
357
FACTORY
PARTS CATALO
VOLTS
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT21P6A
©2002 Electrolux Home Products, Inc.
All rights reserved
G

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT21P6A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FRT21P6A

Summary of Contents for Frigidaire FRT21P6A

  • Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT21P6BSB3 FRT21P6BS R134a stain/blk MARKET North America ENERGY GUIDE - 218791411 OWNER’S GUIDE - 240400106 SERVICE DATA SHEET - 240379010 TOP MOUNT REFRIGERATOR Model No. FRT21P6A ELECTROLUX HOME PRODUCTS, INC P.O.
  • Page 2 Publication No. FRT21P6BSB3 5995379657 DOOR 10/02...
  • Page 3 FRT21P6BSB3 Publication No. 5995379657 DOOR POS. NO PART NO DESCRIPTION 240514611 Gasket,seal ,black ,frzr door ,magnetic 240514612 Gasket,seal ,black ,refr door ,magnetic 240534901 Rack-door 240534701 Rack-door,4A 240337703 Door-dairy,w/o graphics ,clear 240534801 Rack-door 240450331 Door,frzr-RH ,stainless steel 240415204 Label-nameplate,black 240312405 Door Stop,black ,refr 240312406 Door Stop,black ,frzr 240383603...
  • Page 4 Publication No. FRT21P6BSB3 5995379657 CABINET 10/02...
  • Page 5 FRT21P6BSB3 Publication No. 5995379657 CABINET POS. NO PART NO DESCRIPTION 240355402 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240313606 Cover-evap coil 240371303 Seal, insulation, 53.23 in. Long, foam, coil cover 10*# 240524701 Wiring Harness,freezer section...
  • Page 6 Publication No. FRT21P6BSB3 5995379657 SHELVES 10/02...
  • Page 7 FRT21P6BSB3 Publication No. 5995379657 SHELVES POS. NO PART NO DESCRIPTION 215667501 Tray,ice cube ,plastic 240358003 Shelf,freezer ,full-width ,wire 5303299664 Spacer,shelf 240380202 Diffuser,air ,top 240362601 Diffuser,air ,bottom 14 # 240505801 Switch,light/lamp 240436702 Light Bulb/Lamp, A-15, clear, 40 W, 120 V, miniature 241500701 Socket-light/lamp 240368101...
  • Page 8 Publication No. FRT21P6BSB3 5995379657 SYSTEM 10/02...
  • Page 9 FRT21P6BSB3 Publication No. 5995379657 SYSTEM POS. NO PART NO DESCRIPTION 240444401 Condenser,dynamic 218944001 Drier-filter,R134a System 240496101 Wiring Harness,machine compt, w/electric cord 6* # 240388701 Wiring Harness,control box 6* # 240524701 Wiring Harness,freezer section 14 # 5303918247 Defrost Heater Kit 15 # 5303918274 Evaporator Kit 5308000110...

  • Page 10: Wiring Schematic

    Publication No. FRT21P6BSB3 5995379657 WIRING SCHEMATIC 10/02...

  • Page 11: Wiring Diagram

    FRT21P6BSB3 Publication No. 5995379657 WIRING DIAGRAM # = Fast-moving Parts 10/02 * = Non-Illustrated Parts...
