Frigidaire FRT21P6A Factory Parts Catalog
Top mount refrigerator
Hide thumbs
Also See for FRT21P6A:
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages)
Advertisement
Quick Links
PRODUCT NO.
BASE MODEL NO.
FRT21P6BSB2
FRT21P6BS
FRT21P6BSK2
FRT21P6BS
MARKET
North America
ENERGY GUIDE - 218791411
OWNER'S GUIDE - 240400106
SERVICE DATA SHEET - 240379009
SERIES
COLOR
R134a
black (right)
R134a
black (left)
Publication No.
5995372934
020528
-EN/SERVICE/DCS
357
VOLTS
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT21P6A
Advertisement
Related Manuals for Frigidaire FRT21P6A
Summary of Contents for Frigidaire FRT21P6A
- Page 1 PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT21P6BSB2 FRT21P6BS R134a black (right) FRT21P6BSK2 FRT21P6BS R134a black (left) MARKET North America ENERGY GUIDE - 218791411 OWNER’S GUIDE - 240400106 SERVICE DATA SHEET - 240379009 TOP MOUNT REFRIGERATOR Model No. FRT21P6A Publication No.
- Page 2 DOOR...
- Page 3 5995372934 DOOR A = FRT21P6BS (FRT21P6BSB2) B = FRT21P6BS (FRT21P6BSK2) POS. NO PART NO DESCRIPTION 240514611 Gasket,frzr door seal ,black ,magnetic 240514612 Gasket,refr door seal ,black ,magnetic 240331401 Rack-door,20.27" x 1.72" 240311502 Support-door rack,2 liter ,RH 240331502 Support-door rack,gallon ,RH 240311501 Support-door rack,2 liter ,LH 240331501...
- Page 4 CABINET...
- Page 5 5995372934 CABINET A = FRT21P6BS (FRT21P6BSB2) B = FRT21P6BS (FRT21P6BSK2) POS. NO PART NO DESCRIPTION 240355402 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240313606 Cover-evap coil 240371303 Seal,insulation ,53.23 in.
- Page 6 SHELVES...
- Page 7 5995372934 SHELVES A = FRT21P6BS (FRT21P6BSB2) B = FRT21P6BS (FRT21P6BSK2) POS. NO PART NO DESCRIPTION 215667501 Tray,ice cube ,plastic 240358003 Shelf,freezer ,full-width ,wire 5303299664 Spacer,shelf 240380202 Diffuser,air ,top 240362601 Diffuser,air ,bottom 14 # 240505801 Switch,light/lamp 240436702 Light Bulb/Lamp, A-15, clear, 40 W, 120 V,miniature 241500701 Socket-light/lamp 240368101...
- Page 8 SYSTEM...
- Page 9 5995372934 SYSTEM A = FRT21P6BS (FRT21P6BSB2) B = FRT21P6BS (FRT21P6BSK2) POS. NO PART NO DESCRIPTION 240444401 Condenser,dynamic 218944001 Drier-filter,R134a System 240496101 Wiring Harness, machine compt, w/electric cord 6* # 240388701 Wiring Harness,control box 6* # 240524701 Wiring Harness,freezer section 14 # 5303918247 Defrost Heater Kit 15 #...
-
Page 10: Wiring Schematic
WIRING SCHEMATIC... -
Page 11: Wiring Diagram
5995372934 WIRING DIAGRAM...
