Frigidaire FRT21P6CS Factory Parts Catalog
Top mount refrigerator
Hide thumbs
Also See for FRT21P6CS:
- Factory parts catalog (13 pages) ,
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages)
Advertisement
Quick Links
Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet
Installation Instructions 240568300
N05L00003.eps N05DCDBCA1.eps N05BBAABD0.eps N05SABAFE11.eps
N05CAAAAA9.eps
240398801.eps 240398601.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
FRT21P6CSB4 FRT21P6CSB7 FRT21P6CSB9 FRT21P6CSK4 FRT21P6CSK7 FRT21P6CSK9
R134a
R134a
R134a
stain/blk RH
stain/blk RH
stain/blk RH
115
115
115
240398801
240398801
240398801
240400111
240400111
240400111
North America North America North America North America North America North America
240572116
240572116
240572116
240379014
240379014
240379014
240568300
240568300
Publication No.
5995422507
04/11/19
(EN/SERVICE/WC)
390
R134a
R134a
R134a
stain/blk LH
stain/blk LH
stain/blk LH
115
115
115
240398801
240398801
240398801
240400111
240400111
240400111
240572116
240572116
240572116
240379014
240379014
240379014
240568300
240568300
240568300
TOP-MOUNT
REFRIGERATOR
Model No.
FRT21P6CS
©
Copyright
2004 Home Pr
All rights reserved.
oducts, Inc.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRT21P6CS
Summary of Contents for Frigidaire FRT21P6CS
- Page 1 Product No. FRT21P6CSB4 FRT21P6CSB7 FRT21P6CSB9 FRT21P6CSK4 FRT21P6CSK7 FRT21P6CSK9 Series R134a R134a R134a R134a R134a R134a Color stain/blk RH stain/blk RH stain/blk RH stain/blk LH stain/blk LH stain/blk LH Volts Wiring Diagram 240398801 240398801 240398801 240398801 240398801 240398801 Owner's Guide 240400111 240400111 240400111 240400111...
- Page 2 Publication No: 5995422507 FRT21P6CS DOOR N05DCDBCA1 11/04...
- Page 3 FRT21P6CS Publication No: 5995422507 DOOR Model Index: A FRT21P6CS (FRT21P6CSB4) B FRT21P6CS (FRT21P6CSB7) C FRT21P6CS (FRT21P6CSB9) D FRT21P6CS (FRT21P6CSK4) E FRT21P6CS (FRT21P6CSK7) F FRT21P6CS (FRT21P6CSK9) POS. NO PART NO. DESCRIPTION 240514611 A B C D E F Gasket, seal, black, frzr door, magnetic 240514612 A B C D E F Gasket, seal, black, refr door, magnetic...
- Page 4 Publication No: 5995422507 FRT21P6CS CABINET 11/04...
- Page 5 FRT21P6CS Publication No: 5995422507 CABINET Model Index: A FRT21P6CS (FRT21P6CSB4) B FRT21P6CS (FRT21P6CSB7) C FRT21P6CS (FRT21P6CSB9) D FRT21P6CS (FRT21P6CSK4) E FRT21P6CS (FRT21P6CSK7) F FRT21P6CS (FRT21P6CSK9) POS. NO PART NO. DESCRIPTION 240355402 A B C D E F Cover-fan 240367001 A B C D E F Knob-damper control 5303212803 A B C D E F...
- Page 6 Publication No: 5995422507 FRT21P6CS SHELVES 11/04...
- Page 7 FRT21P6CS Publication No: 5995422507 SHELVES Model Index: A FRT21P6CS (FRT21P6CSB4) B FRT21P6CS (FRT21P6CSB7) C FRT21P6CS (FRT21P6CSB9) D FRT21P6CS (FRT21P6CSK4) E FRT21P6CS (FRT21P6CSK7) F FRT21P6CS (FRT21P6CSK9) POS. NO PART NO. DESCRIPTION 215667501 A B C D E F Tray, ice cube, plastic 240358003 A B C D E F Shelf, freezer, full-width, wire...
- Page 8 Publication No: 5995422507 FRT21P6CS SYSTEM N05CAAAAA9 11/04...
- Page 9 FRT21P6CS Publication No: 5995422507 SYSTEM Model Index: A FRT21P6CS (FRT21P6CSB4) B FRT21P6CS (FRT21P6CSB7) C FRT21P6CS (FRT21P6CSB9) D FRT21P6CS (FRT21P6CSK4) E FRT21P6CS (FRT21P6CSK7) F FRT21P6CS (FRT21P6CSK9) POS. NO PART NO. DESCRIPTION 240444401 A B C D E F Condenser, dynamic 218944001 A B C D E F Drier-filter, R134a System 240496101...
-
Page 10: Wiring Schematic
Publication No: 5995422507 FRT21P6CS WIRING SCHEMATIC 11/04... -
Page 11: Wiring Diagram
FRT21P6CS Publication No: 5995422507 WIRING DIAGRAM 11/04 # Functional Parts * Non-Illustrated Parts...
