Frigidaire FRT21P5A Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRT21P5A
  6. Factory parts catalog
Frigidaire FRT21P5A Factory Parts Catalog

Frigidaire FRT21P5A Factory Parts Catalog

Top mount refrigerator
Hide thumbs Also See for FRT21P5A:

Advertisement

Quick Links

Download this manual See also: Factory Parts Catalog
PRODUCT NO.
BASE MODEL NO.
FRT21P5AB6
FRT21P5A
FRT21P5AQ6
FRT21P5A
FRT21P5AW6
FRT21P5A
MARKET
North America
SERIES
COLOR
R134a
black
R134a
bisque
R134a
white
Publication No.
5995372579
020522
-EN/SERVICE/DCS
357
VOLTS
115
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT21P5A

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT21P5A and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRT21P5A

Summary of Contents for Frigidaire FRT21P5A

  • Page 1 PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT21P5AB6 FRT21P5A R134a black FRT21P5AQ6 FRT21P5A R134a bisque FRT21P5AW6 FRT21P5A R134a white MARKET North America TOP MOUNT REFRIGERATOR Model No. FRT21P5A Publication No. 5995372579 020522 -EN/SERVICE/DCS...
  • Page 2 DOOR...
  • Page 3 5995372579 DOOR A = FRT21P5A (FRT21P5AB6) B = FRT21P5A (FRT21P5AQ6) C = FRT21P5A (FRT21P5AW6) POS. NO PART NO DESCRIPTION 240514611 A - - Gasket,frzr door seal ,black ,magnetic 240514607 - B C Gasket,frzr door seal ,white ,magnetic 240514612 A - - Gasket,refr door seal ,black ,magnetic 240514608 - B C...
  • Page 4 CABINET...
  • Page 5 5995372579 CABINET A = FRT21P5A (FRT21P5AB6) B = FRT21P5A (FRT21P5AQ6) C = FRT21P5A (FRT21P5AW6) POS. NO PART NO DESCRIPTION 240355402 A B C Cover-fan 240367001 A B C Knob-damper control 5303001028 A B C Nut,push-on 240367401 A B C Damper-fan cover 5308000010 A B C Fan Blade,red ,evaporator fan...
  • Page 6 SHELVES...
  • Page 7 5995372579 SHELVES A = FRT21P5A (FRT21P5AB6) B = FRT21P5A (FRT21P5AQ6) C = FRT21P5A (FRT21P5AW6) POS. NO PART NO DESCRIPTION 215667501 A B C Tray,ice cube ,plastic 240358003 A B C Shelf,freezer ,full-width ,wire 5303299664 A B C Spacer,shelf 240380202 A B C Diffuser,air ,top 240362601 A B C...
  • Page 8 SYSTEM...
  • Page 9 5995372579 SYSTEM A = FRT21P5A (FRT21P5AB6) B = FRT21P5A (FRT21P5AQ6) C = FRT21P5A (FRT21P5AW6) POS. NO PART NO DESCRIPTION 240444401 A B C Condenser,dynamic 218944001 A B C Drier-filter,R134a System 240496101 A B C Wiring Harness,machine compt, w/electric cord 6* # 240388701 A B C Wiring Harness,control box...

  • Page 10: Wiring Schematic

    WIRING SCHEMATIC...

  • Page 11: Wiring Diagram

    5995372579 WIRING DIAGRAM...
