Speaker (Manual Setup)

Configures the speaker settings manually.
■
Power Amp Assign
Selects a speaker system.
In addition to the 5.1- or 7.1-channel speaker system, various speaker configurations
are possible using the presence speakers, Zone2 speakers, or bi-amp connection.
Settings
Select this option when you use a normal speaker system (not using
Basic (default)
Zone2 speakers or a bi-amp connection).
Select this option when you use Zone2 speakers (p.73) in addition to
7ch +1ZONE
the speaker system in the main zone.
Select this option when you connect front speakers that support
5ch BI-AMP
bi-amp connections (p.21).
■
Configuration
Configures the output characteristics of the speakers.
• When you configure the speaker size, select "Large" if the woofer diameter of your speaker is 16 cm
(6-1/4") or larger or "Small" if it is smaller than 16 cm (6-1/4").
❑ Front
Selects the size of the front speakers.
Settings
Select this option for large speakers.
Large
The front speakers will produce all of the front channel frequency
components.
Select this option for small speakers.
Small (default) The subwoofer will produce front channel low-frequency components
(configurable in "Bass Cross Over").
• "Front" is automatically set to "Large" when "Subwoofer" is set to "None".
❑ Center
Selects whether or not a center speaker is connected and its size.
Settings
Select this option for large speakers.
Large
The center speaker will produce all of the center channel frequency
components.
Select this option for small speakers.
Small (default)
The subwoofer or front speakers will produce center channel
low-frequency components (configurable in "Bass Cross Over").
Select this option when no center speaker is connected.
None
The front speakers will produce center channel audio.
❑ Surround
Selects whether or not surround speakers are connected and their sizes.
Settings
Select this option for large speakers.
Large
The surround speakers will produce all of the surround channel
frequency components.
Select this option for small speakers.
Small (default)
The subwoofer or front speakers will produce surround channel
low-frequency components (configurable in "Bass Cross Over").
Select this option when no surround speakers are connected.
None
The front speakers will produce surround channel audio. Virtual
CINEMA DSP works when you select a sound program.
