Frigidaire FRS24MWG Factory Parts Catalog

Side by side refrigerator
Hide thumbs Also See for FRS24MWG:
Table of Contents

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FRS24MWGW3
FRS24MWG
MARKET
North America
WIRING DIAGRAM - # 218682800
OWNER'S GUIDE - # 218870500
SERVICE DATA SHEET - # 218905000
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a System
white
Publication No.
5995324992
990618
-EN/SERVICE /ECL
357

SIDE BY SIDE

REFRIGERATOR
VOLTS
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS24MWG
©1999 White Consolidated Industries, Inc.
All rights reserved

Advertisement

Table of Contents
loading

Related Manuals for Frigidaire FRS24MWG

Summary of Contents for Frigidaire FRS24MWG

  • Page 1: Side By Side

    FACTORY PARTS CATALOG SIDE BY SIDE REFRIGERATOR PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRS24MWGW3 FRS24MWG R134a System white MARKET North America WIRING DIAGRAM - # 218682800 OWNER’S GUIDE - # 218870500 SERVICE DATA SHEET - # 218905000 SIDE BY SIDE REFRIGERATOR 101 Masters Blvd.

  • Page 2: Freezer Door

    Publication No. FRS24MWGW3 5995324992 FREEZER DOOR 06/99...
  • Page 3 FRS24MWGW3 Publication No. 5995324992 FREEZER DOOR POS. NO PART NO DESCRIPTION 215734313 Gasket-frzr door,white ,magnetic 5303288950 Support-door rack,RH/LH 5303323484 Support-door rack,white ,LH 5303323485 Support-door rack,white ,RH 218807004 Rack-door,w/end caps 215474025 Rack-door 218510601 Panel-inner door,frzr 5303918095 Panel-ext frzr door white,white ,w/foam insulatn 5303289522 Door Stop 218762703...

  • Page 4: Refrigerator Door

    Publication No. FRS24MWGW3 5995324992 REFRIGERATOR DOOR 06/99...
  • Page 5 FRS24MWGW3 Publication No. 5995324992 REFRIGERATOR DOOR POS. NO PART NO DESCRIPTION 215734314 Gasket-refr door,white ,magnetic 215390401 Panel-inner door,refr 218807002 Rack-door,w/end caps 5303288950 Support-door rack,RH/LH 5303308608 Door-dairy 5303289522 Door Stop 5303917498 Panel-refr door,white ,w/foam insulatn 218762703 Handle-door,black 218886801 Screw-8-32 X 1/2 #10 Truss ca,8 32 x 1/2 #10 218578600 Screw-door stop mtg,phl truss hd ,10-16 x 3/4 5303289320...
  • Page 6 Publication No. FRS24MWGW3 5995324992 CABINET 06/99...
  • Page 7 FRS24MWGW3 Publication No. 5995324992 CABINET POS. NO PART NO DESCRIPTION 215637602 Cover-air duct 5303209814 Nut,"U" type ,8-15(A) ,fan mtr mtg 215637401 Cover-evap coil,lower 5303208309 Plug-hole,factory test 215230400 Plug-harness hole 5303289043 Support-air duct cvr,2.55" long 5303289044 Support-air duct cvr,1.83" long 5303289062 Bolt-roller adj,hex head ,5/16-24 x 7/8 215314301 Washer,.40 x .75 x .06 ,nylon...
  • Page 8 Publication No. FRS24MWGW3 5995324992 SHELVES 06/99...
  • Page 9 FRS24MWGW3 Publication No. 5995324992 SHELVES POS. NO PART NO DESCRIPTION 5303298147 Trim-basket 218298003 Shelf-freezer,sliding ,wire 5304405879 Shelf-freezer,fixed wire 11A* 218159700 Spacer-shelf 215919139 Frame-refr shelf,cantilever 218147701 Cover-storage pan 5303307878 Trim-storage pan cvr,upper ,w/humidity hole 5303308340 Control-humidity 218015302 Trim-storage pan cvr,snap-on ,front 218015402 Trim-storage pan cvr,snap-on ,rear 5303289500...
  • Page 10 Publication No. FRS24MWGW3 5995324992 CONTROLS 06/99...
  • Page 11 FRS24MWGW3 Publication No. 5995324992 CONTROLS POS. NO PART NO DESCRIPTION 215028605 Knob-damper control 5308000010 Fan Blade,red 5308000124 Ring-fan orifice 5300157666 Bushing-motor mtg,(2) 5303205118 Bracket-motor mtg,front 215809600 Diffuser-air 13 # 215426200 Motor-evap fan 215474201 Washer,"slinger" ,nylon ,evap fan shaft 5303205119 Bracket-motor mtg,rear 5303001179 Light Bulb/Lamp,40 W 5303289050...
  • Page 12 Publication No. FRS24MWGW3 5995324992 SYSTEM 06/99...
  • Page 13 FRS24MWGW3 Publication No. 5995324992 SYSTEM POS. NO PART NO DESCRIPTION 218787900 Condenser 5303208866 Spacer-cond tube,black 5303289026 Spacer-tube 5303289029 Clip-cond mtg,(4) 218679603 Block-evap coil,styrofoam ,(2) 218944001 Drier-filter,R134a System 218646100 Harness-wiring,main 215005200 Harness-wiring,refr controls 218815101 Harness-wiring,frzr controls 218897101 Harness-wiring,machine compt 215459201 Cord-electric power 218803400 Cover-wiring 13 #...
  • Page 14 Publication No. FRS24MWGW3 5995324992 DISPENSER 06/99...
  • Page 15 FRS24MWGW3 Publication No. 5995324992 DISPENSER POS. NO PART NO DESCRIPTION 5318582501 Tube-water inlet,93" ,plastic ,cut-to-size 215294101 Tube-water inlet,formed ,plastic ,dispenser 218505301 Deflector-ice disp,white 215484300 Heater-door housing 218432101 Housing-dispenser,white 218841901 Switch-actuator,micro 215944300 Shield-micro switch 218835701 Module-dispenser 218209800 Spring,dispenser door 218836201 Knob-selector,white 215748101 Ring-snap,actuator 218416158...

  • Page 16: Ice Container

    Publication No. FRS24MWGW3 5995324992 ICE CONTAINER 06/99...
  • Page 17 FRS24MWGW3 Publication No. 5995324992 ICE CONTAINER POS. NO PART NO DESCRIPTION 5304404344 Auger-ice 5304404343 Cam-drive 218815300 Container-ice 5304404346 Drum-ice disp 218815400 Front-ice container 5304404337 Bar-drive 5304404359 Gate 5303001179 Light Bulb/Lamp,40 W 5303289050 Socket-light/lamp 5304404345 Drive Blade 18 # 5304404330 Motor-auger 5304404335 Harness-wiring,auger motor 5304404332...

  • Page 18: Ice Maker

    Publication No. FRS24MWGW3 5995324992 ICE MAKER 06/99...
  • Page 19 FRS24MWGW3 Publication No. 5995324992 ICE MAKER POS. NO PART NO DESCRIPTION 5318582501 Tube-water inlet,93" ,plastic ,cut-to-size 3206348 Spring,shut-off arm 3206299 Plate-I.D. 3206301 Gear 3206303 Plate-mounting 3206305 Screw-ground wire,8-32 x 1/4 3206306 Motor-ice maker 3206312 Spacer-holding sw 3206313 3206315 Clamp 11 # 3206319 Thermal Cutoff,icemaker ,complete assy 12 #...

  • Page 20: Wiring Schematic

    Publication No. FRS24MWGW3 5995324992 WIRING SCHEMATIC 06/99...

  • Page 21: Wiring Diagram

    FRS24MWGW3 Publication No. 5995324992 WIRING DIAGRAM # = Fast-moving Parts 06/99 * = Non-Illustrated Parts...
