Frigidaire FRS24ZRH Factory Parts Catalog

Frigidaire FRS24ZRH Factory Parts Catalog

Side by side refrigerator
Hide thumbs Also See for FRS24ZRH:

Advertisement

Table of Contents

PRODUCT NO.
BASE MODEL NO.
FRS24ZRHB4
FRS24ZRH
FRS24ZRHD4
FRS24ZRH
FRS24ZRHW4
FRS24ZRH
MARKET
North American
WIRING DIAGRAM - # 218903201
OWNER'S GUIDE - # 218955100
SERVICE DATA SHEET - # 218905001
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a
black
R134a
almond
R134a
white
Publication No.
5995342200
000808
-EN/SERVICE/KHB
357

SIDE BY SIDE

REFRIGERATOR
VOLTS
115
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS24ZRH
©2000 White Consolidated Industries, Inc.
All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS24ZRH and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRS24ZRH

Summary of Contents for Frigidaire FRS24ZRH

  • Page 1: Side By Side

    PRODUCT NO. BASE MODEL NO. FRS24ZRHB4 FRS24ZRH FRS24ZRHD4 FRS24ZRH FRS24ZRHW4 FRS24ZRH MARKET North American WIRING DIAGRAM - # 218903201 OWNER’S GUIDE - # 218955100 SERVICE DATA SHEET - # 218905001 101 Masters Blvd. Anderson, SC 29624 FACTORY PARTS CATALOG REFRIGERATOR...

  • Page 2: Freezer Door

    Publication No. FRS24ZRH 5995342200 FREEZER DOOR 08/00...
  • Page 3 A = FRS24ZRH (FRS24ZRHB4) B = FRS24ZRH (FRS24ZRHD4) C = FRS24ZRH (FRS24ZRHW4) POS. NO 37A* 37A* # = Fast-moving Parts * = Non-Illustrated Parts FRS24ZRH FREEZER DOOR PART NO DESCRIPTION 215734323 A - - Gasket-frzr door,black ,magnetic 215734313 - B C...

  • Page 4: Refrigerator Door

    Publication No. FRS24ZRH 5995342200 REFRIGERATOR DOOR 08/00...
  • Page 5 A = FRS24ZRH (FRS24ZRHB4) B = FRS24ZRH (FRS24ZRHD4) C = FRS24ZRH (FRS24ZRHW4) POS. NO 37A* 37A* # = Fast-moving Parts * = Non-Illustrated Parts FRS24ZRH REFRIGERATOR DOOR PART NO DESCRIPTION 215734324 A - - Gasket-refr door,black ,magnetic 215734314 - B C...
  • Page 6 Publication No. FRS24ZRH 5995342200 CABINET 08/00...
  • Page 7 A = FRS24ZRH (FRS24ZRHB4) B = FRS24ZRH (FRS24ZRHD4) C = FRS24ZRH (FRS24ZRHW4) POS. NO 10A* 30A* 101* # = Fast-moving Parts * = Non-Illustrated Parts FRS24ZRH CABINET PART NO DESCRIPTION 215637602 A B C Cover-air duct 5303209814 A B C Nut,"U"...
  • Page 8 Publication No. FRS24ZRH 5995342200 SHELVES 08/00...
  • Page 9 A = FRS24ZRH (FRS24ZRHB4) B = FRS24ZRH (FRS24ZRHD4) C = FRS24ZRH (FRS24ZRHW4) POS. NO 52A* 100A 100B # = Fast-moving Parts * = Non-Illustrated Parts FRS24ZRH SHELVES PART NO DESCRIPTION 5303298147 A B C Trim-basket 218298003 A B C Shelf-freezer,sliding ,wire...
  • Page 10 Publication No. FRS24ZRH 5995342200 CONTROLS 08/00...
  • Page 11 A = FRS24ZRH (FRS24ZRHB4) B = FRS24ZRH (FRS24ZRHD4) C = FRS24ZRH (FRS24ZRHW4) POS. NO 13 # 16 # 17A* 21 # 23 # 114# 125# 141# 141* 143* # = Fast-moving Parts * = Non-Illustrated Parts FRS24ZRH CONTROLS PART NO...
  • Page 12 Publication No. FRS24ZRH 5995342200 SYSTEM 08/00...
  • Page 13 A = FRS24ZRH (FRS24ZRHB4) B = FRS24ZRH (FRS24ZRHD4) C = FRS24ZRH (FRS24ZRHW4) POS. NO 13 # 14 # 15 # 21 # 29 # 30 # 54A* 55 # 60 # # = Fast-moving Parts * = Non-Illustrated Parts FRS24ZRH...
  • Page 14 Publication No. FRS24ZRH 5995342200 DISPENSER 08/00...
  • Page 15 A = FRS24ZRH (FRS24ZRHB4) B = FRS24ZRH (FRS24ZRHD4) C = FRS24ZRH (FRS24ZRHW4) POS. NO 12A* 17A* 35 # 38A# 38B# # = Fast-moving Parts * = Non-Illustrated Parts FRS24ZRH DISPENSER PART NO DESCRIPTION 5308010366 A B C Tube-water inlet, 0.25 OD x 93", plastic...

  • Page 16: Ice Container

    Publication No. FRS24ZRH 5995342200 ICE CONTAINER 08/00...
  • Page 17 A = FRS24ZRH (FRS24ZRHB4) B = FRS24ZRH (FRS24ZRHD4) C = FRS24ZRH (FRS24ZRHW4) POS. NO 18 # 45 # # = Fast-moving Parts * = Non-Illustrated Parts FRS24ZRH ICE CONTAINER PART NO DESCRIPTION 5304404344 A B C Auger-ice 5304404343 A B C...

  • Page 18: Ice Maker

    Publication No. FRS24ZRH 5995342200 ICE MAKER 08/00...
  • Page 19 A = FRS24ZRH (FRS24ZRHB4) B = FRS24ZRH (FRS24ZRHD4) C = FRS24ZRH (FRS24ZRHW4) POS. NO 11 # 12 # 13 # 15 # 17 # 141# # = Fast-moving Parts * = Non-Illustrated Parts FRS24ZRH ICE MAKER PART NO DESCRIPTION 5308010366 A B C Tube-water inlet, 0.25 OD x 93", plastic...

  • Page 20: Wiring Schematic

    Publication No. FRS24ZRH 5995342200 WIRING SCHEMATIC 08/00...

  • Page 21: Wiring Diagram

    FRS24ZRH Publication No. 5995342200 WIRING DIAGRAM # = Fast-moving Parts 08/00 * = Non-Illustrated Parts...
