Frigidaire FRS24WSG Factory Parts Catalog
Side by side refrigerator
Hide thumbs
Also See for FRS24WSG:
- User manual (21 pages) ,
- Factory parts catalog (22 pages) ,
- Factory parts catalog (21 pages)
Advertisement
Quick Links
Download this manual
See also:
User Manual
Advertisement
Related Manuals for Frigidaire FRS24WSG
Summary of Contents for Frigidaire FRS24WSG
- Page 1 FRS24WSGD0 FRS24WSG FRS24WSGD1 FRS24WSG FRS24WSGW0 FRS24WSG FRS24WSGW1 FRS24WSG 101 Masters Blvd. Anderson, SC 29624 almond almond white white Publication No. 5995310850 980727 -EN/SERVICE /JLT ©1998 White Consolidated Industries, Inc. All rights reserved...
-
Page 2: Freezer Door
Publication No. FRS24WSG 5995310850 FREEZER DOOR 07/98... - Page 3 A = FRS24WSG (FRS24WSGD0) B = FRS24WSG (FRS24WSGD1) C = FRS24WSG (FRS24WSGW0) D = FRS24WSG (FRS24WSGW1) 37A* 37A* 37A* # = Fast-moving Parts * = Non-Illustrated Parts FRS24WSG FREEZER DOOR 215734303 A B - - Gasket-frzr door,almond ,magnetic 215734313 - - C D...
-
Page 4: Refrigerator Door
Publication No. FRS24WSG 5995310850 REFRIGERATOR DOOR 07/98... - Page 5 A = FRS24WSG (FRS24WSGD0) B = FRS24WSG (FRS24WSGD1) C = FRS24WSG (FRS24WSGW0) D = FRS24WSG (FRS24WSGW1) 37A* 37A* 37A* # = Fast-moving Parts * = Non-Illustrated Parts FRS24WSG REFRIGERATOR DOOR 215734304 A B - - Gasket-refr door,almond ,magnetic 215734314 - - C D...
- Page 6 Publication No. FRS24WSG 5995310850 CABINET 07/98...
- Page 7 A = FRS24WSG (FRS24WSGD0) B = FRS24WSG (FRS24WSGD1) C = FRS24WSG (FRS24WSGW0) D = FRS24WSG (FRS24WSGW1) 30A* # = Fast-moving Parts * = Non-Illustrated Parts FRS24WSG CABINET 215637602 A B C D Cover-air duct 215637400 A B C D Cover-evap coil,lower...
- Page 8 Publication No. FRS24WSG 5995310850 SHELVES 07/98...
- Page 9 A = FRS24WSG (FRS24WSGD0) B = FRS24WSG (FRS24WSGD1) C = FRS24WSG (FRS24WSGW0) D = FRS24WSG (FRS24WSGW1) 100A 100B 126* # = Fast-moving Parts * = Non-Illustrated Parts FRS24WSG SHELVES 5303298147 A B C D Trim-basket 218298003 A B C D...
- Page 10 Publication No. FRS24WSG 5995310850 CONTROLS 07/98...
- Page 11 A = FRS24WSG (FRS24WSGD0) B = FRS24WSG (FRS24WSGD1) C = FRS24WSG (FRS24WSGW0) D = FRS24WSG (FRS24WSGW1) 13 # 16 # 21 # 23 # 114# 115# 125# # = Fast-moving Parts * = Non-Illustrated Parts FRS24WSG CONTROLS 215028605 A B C D...
- Page 12 Publication No. FRS24WSG 5995310850 SYSTEM 07/98...
- Page 13 A = FRS24WSG (FRS24WSGD0) B = FRS24WSG (FRS24WSGD1) C = FRS24WSG (FRS24WSGW0) D = FRS24WSG (FRS24WSGW1) 13 # 13 # 14 # 15 # 21 # 29 # 29 # 30 # 30 # 31 # 31 # 55 #...
- Page 14 Publication No. FRS24WSG 5995310850 DISPENSER 07/98...
- Page 15 A = FRS24WSG (FRS24WSGD0) B = FRS24WSG (FRS24WSGD1) C = FRS24WSG (FRS24WSGW0) D = FRS24WSG (FRS24WSGW1) 17A* 33 # 33 # 35 # 38A# 38B# # = Fast-moving Parts * = Non-Illustrated Parts FRS24WSG DISPENSER 5308010366 A B C D Tube-water inlet,93"...
-
Page 16: Ice Container
Publication No. FRS24WSG 5995310850 ICE CONTAINER 07/98... - Page 17 A = FRS24WSG (FRS24WSGD0) B = FRS24WSG (FRS24WSGD1) C = FRS24WSG (FRS24WSGW0) D = FRS24WSG (FRS24WSGW1) 18 # 45 # # = Fast-moving Parts * = Non-Illustrated Parts FRS24WSG ICE CONTAINER 5304404344 A B C D Auger-ice 5304404343 A B C D...
-
Page 18: Ice Maker
Publication No. FRS24WSG 5995310850 ICE MAKER 07/98... - Page 19 A = FRS24WSG (FRS24WSGD0) B = FRS24WSG (FRS24WSGD1) C = FRS24WSG (FRS24WSGW0) D = FRS24WSG (FRS24WSGW1) 11 # 12 # 13 # 15 # 17 # 55 # 141# # = Fast-moving Parts * = Non-Illustrated Parts FRS24WSG ICE MAKER...
- Page 20 Publication No. FRS24WSG 5995310850 WIRING 07/98...
- Page 21 FRS24WSG Publication No. 5995310850 WIRING # = Fast-moving Parts 07/98 * = Non-Illustrated Parts...
