Frigidaire FRS24ZRG Factory Parts Catalog

Frigidaire FRS24ZRG Factory Parts Catalog

Side by side refrigerator
Hide thumbs Also See for FRS24ZRG:

Advertisement

Quick Links

Download this manual
FRS24ZRGB0
FRS24ZRG
FRS24ZRGD0
FRS24ZRG
FRS24ZRGW0
FRS24ZRG
101 Masters Blvd.
Anderson, SC 29624
R134a
black
R134a
almond
R134a
white
Publication No.
5995311106
980804
-EN/SERVICE /JLT
357
115
115
115
©1998 White Consolidated Industries, Inc.
All rights reserved

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRS24ZRG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FRS24ZRG

Summary of Contents for Frigidaire FRS24ZRG

  • Page 1 FRS24ZRGB0 FRS24ZRG R134a black FRS24ZRGD0 FRS24ZRG R134a almond FRS24ZRGW0 FRS24ZRG R134a white 101 Masters Blvd. Anderson, SC 29624 Publication No. 5995311106 980804 -EN/SERVICE /JLT ©1998 White Consolidated Industries, Inc. All rights reserved...

  • Page 2: Freezer Door

    Publication No. FRS24ZRG 5995311106 FREEZER DOOR 08/98...
  • Page 3 FRS24ZRG Publication No. 5995311106 FREEZER DOOR A = FRS24ZRB (FRS24ZRGB0) B = FRS24ZRG (FRS24ZRGD0) C = FRS24ZRG (FRS24ZRGW0) 215734323 A - - Gasket-frzr door,black ,magnetic 215734303 - B - Gasket-frzr door,almond ,magnetic 215734313 - - C Gasket-frzr door,white ,magnetic 5303288950 A B C Support-door rack,RH/LH 5303323484...

  • Page 4: Refrigerator Door

    Publication No. FRS24ZRG 5995311106 REFRIGERATOR DOOR 08/98...
  • Page 5 FRS24ZRG Publication No. 5995311106 REFRIGERATOR DOOR A = FRS24ZRB (FRS24ZRGB0) B = FRS24ZRG (FRS24ZRGD0) C = FRS24ZRG (FRS24ZRGW0) 215734324 A - - Gasket-refr door,black ,magnetic 215734304 - B - Gasket-refr door,almond ,magnetic 215734314 - - C Gasket-refr door,white ,magnetic 215390401 A B C Panel-inner door,refr 218807011...
  • Page 6 Publication No. FRS24ZRG 5995311106 CABINET 08/98...
  • Page 7 FRS24ZRG Publication No. 5995311106 CABINET A = FRS24ZRB (FRS24ZRGB0) B = FRS24ZRG (FRS24ZRGD0) C = FRS24ZRG (FRS24ZRGW0) 215637602 A B C Cover-air duct 5303209814 A B C Nut,"U" type ,8-15(A) ,fan mtr mtg 215637401 A B C Cover-evap coil,lower 10A* 5308009617 A B C Washer,ext tooth lock ,#10...
  • Page 8 Publication No. FRS24ZRG 5995311106 SHELVES 08/98...
  • Page 9 FRS24ZRG Publication No. 5995311106 SHELVES 5303298147 A B C Trim-basket 218298003 A B C Shelf-freezer,sliding ,wire 5303296576 A B C Shelf-freezer,fixed wire 218815501 A B C Shelf-pizza,24B 5308007097 A B C Screw,cr truss head ,8-15A x 0.750 215406129 A B C Shelf-"Spill-Safe",fixed ,(3) 218147701 A B C...
  • Page 10 Publication No. FRS24ZRG 5995311106 CONTROLS 08/98...
  • Page 11 FRS24ZRG Publication No. 5995311106 CONTROLS 215028605 - B C Knob-damper control 5308000010 A B C Fan Blade,red 5308000124 A B C Ring-fan orifice 5300157666 A B C Bushing-motor mtg,(2) 5303205118 A B C Bracket-motor mtg,front 215809600 A B C Diffuser-air 13 # 215426200 A B C...
  • Page 12 Publication No. FRS24ZRG 5995311106 SYSTEM 08/98...
  • Page 13 FRS24ZRG Publication No. 5995311106 SYSTEM 218787900 A B C Condenser 5303208866 A B C Spacer-tube 5303289026 A B C Spacer-tube 5303289029 A B C Clip-cond mtg,(4) 218679603 A B C Block-evap coil,styrofoam ,(2) 218541000 A B C Drier-filter 218646100 A B C Harness-wiring,main 215005200 A B C...
  • Page 14 Publication No. FRS24ZRG 5995311106 DISPENSER 08/98...
  • Page 15 FRS24ZRG Publication No. 5995311106 DISPENSER A = FRS24ZRB (FRS24ZRGB0) B = FRS24ZRG (FRS24ZRGD0) C = FRS24ZRG (FRS24ZRGW0) 5308010366 A B C Tube-water inlet,93" ,plastic ,cut-to-length 215294101 A B C Tube-water inlet,formed ,plastic ,dispenser 218658301 A B C Tube-water inlet,filter ,to filter valve,w/elbow 218770401 A B C Tube-water inlet,inlet valve ,to filter...

  • Page 16: Ice Container

    Publication No. FRS24ZRG 5995311106 ICE CONTAINER 08/98...
  • Page 17 FRS24ZRG Publication No. 5995311106 ICE CONTAINER A = FRS24ZRB (FRS24ZRGB0) B = FRS24ZRG (FRS24ZRGD0) C = FRS24ZRG (FRS24ZRGW0) 5304404344 A B C Auger-ice 5304404343 A B C Cam-drive 218815300 A B C Container-ice 5304404346 A B C Drum-ice disp 218815400 A B C Front-ice container 5304404337...

  • Page 18: Ice Maker

    Publication No. FRS24ZRG 5995311106 ICE MAKER 08/98...
  • Page 19 FRS24ZRG Publication No. 5995311106 ICE MAKER A = FRS24ZRB (FRS24ZRGB0) B = FRS24ZRG (FRS24ZRGD0) C = FRS24ZRG (FRS24ZRGW0) 5308010366 A B C Tube-water inlet,93" ,plastic ,cut-to-length 218658301 A B C Tube-water inlet,filter ,to filter valve,w/elbow 218703400 A B C Tube-water inlet,inlet valve ,to filter 218770401 A B C Tube-water inlet,inlet valve ,to filter...
  • Page 20 Publication No. FRS24ZRG 5995311106 WIRING 08/98...
  • Page 21 FRS24ZRG Publication No. 5995311106 WIRING # = Fast-moving Parts 08/98 * = Non-Illustrated Parts...
