Frigidaire FRS24MWG Factory Parts Catalog

Frigidaire FRS24MWG Factory Parts Catalog

Side by side refrigerator
Hide thumbs Also See for FRS24MWG:
Table of Contents

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FRS24MWGD2
FRS24MWG
FRS24MWGW2
FRS24MWG
MARKET
North American
WIRING DIAGRAM - # 218682800
OWNER'S GUIDE - # 218870500
SERVICE DATA SHEET - # 218905000
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a System
almond
R134a System
white
Publication No.
5995318861
990303
-EN/SERVICE/KB
357

SIDE BY SIDE

REFRIGERATOR
VOLTS
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS24MWG
©1999 White Consolidated Industries, Inc.
All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS24MWG and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRS24MWG

Summary of Contents for Frigidaire FRS24MWG

  • Page 1: Side By Side

    FACTORY PARTS CATALOG SIDE BY SIDE REFRIGERATOR PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRS24MWGD2 FRS24MWG R134a System almond FRS24MWGW2 FRS24MWG R134a System white MARKET North American WIRING DIAGRAM - # 218682800 OWNER’S GUIDE - # 218870500 SERVICE DATA SHEET - # 218905000 SIDE BY SIDE REFRIGERATOR 101 Masters Blvd.

  • Page 2: Freezer Door

    Publication No. FRS24MWG 5995318861 FREEZER DOOR 03/99...
  • Page 3 FRS24MWG Publication No. 5995318861 FREEZER DOOR A = FRS24MWG (FRS24MWGD2) B = FRS24MWG (FRS24MWGW2) POS. NO PART NO DESCRIPTION 215734303 Gasket-frzr door,almond ,magnetic 215734313 Gasket-frzr door,white ,magnetic 5303288950 Support-door rack,RH/LH 5303323484 Support-door rack,white ,LH 5303323485 Support-door rack,white ,RH 218807004 Rack-door,w/end caps 215474025 Rack-door 218510601...

  • Page 4: Refrigerator Door

    Publication No. FRS24MWG 5995318861 REFRIGERATOR DOOR 03/99...
  • Page 5 FRS24MWG Publication No. 5995318861 REFRIGERATOR DOOR A = FRS24MWG (FRS24MWGD2) B = FRS24MWG (FRS24MWGW2) POS. NO PART NO DESCRIPTION 215734304 Gasket-refr door,almond ,magnetic 215734314 Gasket-refr door,white ,magnetic 215390401 Panel-inner door,refr 218807002 Rack-door,w/end caps 5303288950 Support-door rack,RH/LH 5303308608 Door-dairy 5303289522 Door Stop 5303917499 Panel-refr door,almond ,w/foam insulatn 5303917498...
  • Page 6 Publication No. FRS24MWG 5995318861 CABINET 03/99...
  • Page 7 FRS24MWG Publication No. 5995318861 CABINET A = FRS24MWG (FRS24MWGD2) B = FRS24MWG (FRS24MWGW2) POS. NO PART NO DESCRIPTION 215637602 Cover-air duct 5308009617 Washer,ext tooth lock ,#10 215637401 Cover-evap coil,lower 5303208309 Plug-hole,factory test 215230400 Plug-harness hole 5303289043 Support-air duct cvr,2.55" long 5303289044 Support-air duct cvr,1.83"...
  • Page 8 Publication No. FRS24MWG 5995318861 SHELVES 03/99...
  • Page 9 FRS24MWG Publication No. 5995318861 SHELVES A = FRS24MWG (FRS24MWGD2) B = FRS24MWG (FRS24MWGW2) POS. NO PART NO DESCRIPTION 5303298147 Trim-basket 218298003 Shelf-freezer,sliding ,wire 5304405879 Shelf-freezer,fixed wire 215919139 Frame-refr shelf,cantilever 218147701 Cover-storage pan 5303307878 Trim-storage pan cvr, upper, w/humidity hole 5303308340 Control-humidity 218015302 Trim-storage pan cvr,snap-on ,front...
  • Page 10 Publication No. FRS24MWG 5995318861 CONTROLS 03/99...
  • Page 11 FRS24MWG Publication No. 5995318861 CONTROLS A = FRS24MWG (FRS24MWGD2) B = FRS24MWG (FRS24MWGW2) POS. NO PART NO DESCRIPTION 215028605 Knob-damper control 5308000010 Fan Blade,red 5308000124 Ring-fan orifice 5300157666 Bushing-motor mtg,(2) 5303205118 Bracket-motor mtg,front 215809600 Diffuser-air 13 # 215426200 Motor-evap fan 215474201 Washer,"slinger"...
  • Page 12 Publication No. FRS24MWG 5995318861 SYSTEM 03/99...
  • Page 13 FRS24MWG Publication No. 5995318861 SYSTEM A = FRS24MWG (FRS24MWGD2) B = FRS24MWG (FRS24MWGW2) POS. NO PART NO DESCRIPTION 218787900 Condenser 5303208866 Spacer-tube 5303289026 Spacer-tube 5303289029 Clip-cond mtg,(4) 218679603 Block-evap coil,styrofoam ,(2) 218541000 Drier-filter 218646100 Harness-wiring,main 215005200 Harness-wiring,refr controls 218815101 Harness-wiring,frzr controls 218897101 Harness-wiring,machine compt 215459201...
  • Page 14 Publication No. FRS24MWG 5995318861 DISPENSER 03/99...
  • Page 15 FRS24MWG Publication No. 5995318861 DISPENSER A = FRS24MWG (FRS24MWGD2) B = FRS24MWG (FRS24MWGW2) POS. NO PART NO DESCRIPTION 5318582501 Tube-water inlet, 93", plastic, cut-to-size 215294101 Tube-water inlet, formed, plastic, dispenser 218505302 Deflector-ice disp,almond 218505301 Deflector-ice disp,white 215484300 Heater-door housing 218432102 Housing-dispenser,almond 218432101 Housing-dispenser,white...

  • Page 16: Ice Container

    Publication No. FRS24MWG 5995318861 ICE CONTAINER 03/99...
  • Page 17 FRS24MWG Publication No. 5995318861 ICE CONTAINER A = FRS24MWG (FRS24MWGD2) B = FRS24MWG (FRS24MWGW2) POS. NO PART NO DESCRIPTION 5304404344 Auger-ice 5304404343 Cam-drive 218815300 Container-ice 5304404346 Drum-ice disp 218815400 Front-ice container 5304404337 Bar-drive 5304404359 Gate 5303001179 Light Bulb/Lamp,40 W 5303289050 Socket-light/lamp 5304404345 Drive Blade...

  • Page 18: Ice Maker

    Publication No. FRS24MWG 5995318861 ICE MAKER 03/99...
  • Page 19 FRS24MWG Publication No. 5995318861 ICE MAKER A = FRS24MWG (FRS24MWGD2) B = FRS24MWG (FRS24MWGW2) POS. NO PART NO DESCRIPTION 5318582501 Tube-water inlet, 93", plastic, cut-to-size 3206348 Spring,shut-off arm 3206299 Plate-I.D. 3206301 Gear 3206303 Plate-mounting 3206305 Screw-ground wire,8-32 x 1/4 3206306 Motor-ice maker 3206312 Spacer-holding sw...

  • Page 20: Wiring Schematic

    Publication No. FRS24MWG 5995318861 WIRING SCHEMATIC 03/99...

  • Page 21: Wiring Diagram

    FRS24MWG Publication No. 5995318861 WIRING DIAGRAM # = Fast-moving Parts 03/99 * = Non-Illustrated Parts...
