PRODUCT NO.
BASE MODEL NO.
FRS24AGGB9
FRS24AGG
FRS24AGGW9
FRS24AGG
MARKET
North America
WIRING DIAGRAM - # 5304416100
OWNER'S GUIDE - # 5304413840
SERVICE DATA SHEET - # 5304416100
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
FACTORY PARTS CATALOG
SERIES
COLOR
R134a
black
R134a
white
Publication No.
5995345781
001027
-EN/SERVICE /ECL
099

SIDE BY SIDE

REFRIGERATOR
VOLTS
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS24AGG
©2000 White Consolidated Industries, Inc.
All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS24AGG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FRS24AGG

Summary of Contents for Frigidaire FRS24AGG

  • Page 1: Side By Side

    PRODUCT NO. BASE MODEL NO. FRS24AGGB9 FRS24AGG FRS24AGGW9 FRS24AGG MARKET North America WIRING DIAGRAM - # 5304416100 OWNER’S GUIDE - # 5304413840 SERVICE DATA SHEET - # 5304416100 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O. Box 212378, Augusta, GA 30917 FACTORY PARTS CATALOG...
