- Page 1 Versatile Monitoring Software User’s Manual...
-
Page 2: Introduction
All possible measures have been taken to ensure that the content of this manual is accurate. If you happen to notice errors, omissions or other faults, please contact Canon. Irrespective of items above, Canon accepts no liability for any results arising from the operation of this product. -
Page 3: Table Of Contents
Contents Introduction ............2 1. Overview ............4 2. System Configuration ........5 Example of System Configuration ........5 Operating Environment ............5 3. Installing ............6 Prior to Installation.............. 6 Preparing the PC ................6 Installing the Camera Servers ............6 Installation ................ -
Page 4: Overview
Overview WebView Livescope MV Ver. 2.1 LE (hereafter referred to as MV LE) is software that allows you to use an Intranet or the Internet to monitor video distributed from the Network Camera Server VB150/VB101 or the Network Camera VB-C10/VB-C10R (hereafter referred to as “camera server”). Since MV LE uses the wizard format for registering camera servers, there is no need to learn complex operations. -
Page 5: System Configuration
System Configuration MV LE connects to camera servers using TCP/IP protocol. Connections can be made via the Internet or an Intranet. Example of System Configuration L A N Distributes video and picture data VC-C4 VC-C4R VB101 ISDN Line Router Monitoring VB-C10 MV LE Monitoring via ISDN line... -
Page 6: Installing
However, if the VB101 is being used, check to be sure that the firmware version is 3.0 or later. The firmware is available for free at the following. URL:http://www.canon.com/webview/ Check to be sure the camera server has been correctly installed and that the initial settings (network settings) have been made. -
Page 7: Installation
Installation When you load the WebView Livescope MV LE installer CD-ROM, the installer automatically starts and the installation process begins. If it does not start, in Explorer, double-click “Setup.exe” on the CD-ROM and click Next to proceed with the installation. Enter the Serial number and click Next. -
Page 8: Registering The Cameras
Registering the Cameras Cameras must be registered in order to monitor images from them with MV LE. There are two ways to register a camera: Using “Register Camera” in which the network address of a camera server is entered manually, and “Search Camera” in which camera servers connected to the network are automatically searched and detected cameras are registered. -
Page 9: Registering Cameras Using "Search Camera
Make sure that the camera you just registered appears in the Registered cameras list. To register more than one camera from a different camera server, repeat the procedure from step 1 . When you click OK, images from the registered camera can be viewed. -
Page 10: Operating From The Menus
Operating from the Menus Menu Bar This chapter describes operating procedures using the menus. Menu Bar Operation menu “Register Camera” Lets you register camera servers or change camera orders. “Option” Lets you set Video Relay or set the HTTP Port and HTTP Proxy. “Exit”... -
Page 11: Detailed Settings
Detailed Settings Changing the Registration Order of Cameras An order is set for camera registrations. The position of viewers in which images are displayed and the order of video relays are specified according to this order. The order can be changed after registrations. -
Page 12: Operating From The Toolbar
Operating from the Toolbar Toolbar This chapter describes operating procedures using the toolbar Toolbar “4 Viewers” Switches to 4 viewers display. “1 Viewer (Large)” Switches to 1 viewer (large) display. “1 Viewer (Normal)” Switches to 1 viewer (normal) display. “Camera Switch Box” Switches among cameras displayed in the viewer (during 1 Viewer display only). -
Page 13: Main Operations
Main Operations Switching Viewer Display Methods There are three methods in which viewers can be displayed: 4 Viewers display, 1 Viewer (Large) display, and 1 Viewer (Normal) display. Display can be switched by clicking on the 4 Viewers, 1 Viewer (Large), and the 1 Viewer (Normal) buttons on the toolbar. Choose the method that best suits your needs. -
Page 14: Switching Cameras Being Viewed
Switching Cameras being Viewed During 1 Viewer display, if more than one camera has been registered, the camera displayed in the viewer can be switched. To switch cameras, click [2] in the Camera Switch box to select the camera from the list. The order of the cameras shown in the list is the order in which the cameras were registered. -
Page 15: Displaying Full Screens
Operating from the Toolbar Displaying Full Screens Images in a selected viewer can be displayed on the entire screen. Click on the viewer to select it, then click the Full Screen button on the toolbar. When you click anywhere on the full screen display, the camera’s pan and tilt are controlled so that that position becomes the center of the image. -
Page 16: Operating The Cameras
Operating the Cameras MV LE lets you freely control the cameras and monitor them. The cameras can be controlled from the Camera Control Panel or on the viewer. Operating Cameras from the Camera Control Panel Operating a Camera with the Control Buttons A camera can be freely controlled using the Pan, Tilt, and Zoom buttons. -
Page 17: Controlling The Camera With Panorama
Controlling the Camera with Panorama Pan, Tilt, and Zoom can be freely controlled from the Panorama. To change Pan and Tilt by clicking When you click on a specific point on the panorama picture, the frame moves and the pan and tilt change to make that point the center of the picture. -
Page 18: Options
Options Option in the Operation menu lets you make Video Relay and HTTP settings. Setting the Video Relay Since only one viewer among a number of viewers can be used to display live video, Video Relay automatically switches from more than one camera connected to a single camera server. The use of this function can avoid clicking manually on individual viewers to switch video display. -
Page 19: Troubleshooting
Troubleshooting Cannot install When using Windows 2000, or Windows XP Professional, see if you have logged-in as an administrator. Cannot register camera server Refer to error messages (1) - (7). If camera server is being accessed via a proxy, be sure to set the proxy in Option under the Operation menu. -
Page 20: Error Messages
Error Messages (1) Network connection errors (DNS errors): Camera server registration error [01] Message The camera server could not be found. Make sure: • The network address is correct. • DNS setting is correct. Cause The specified network address could not be found. Action to •... - Page 21 (5) VIEW-Windows mode: Camera server registration error [05] Message The camera server is not set up properly. Make sure: [Target Application] of [Basic Settings] is set to [WebView Livescope]. The camera server application mode is set to VIEW-Windows mode. Cause Set the camera server application mode to WebView Livescope mode.
- Page 22 (10) When switching to appropriate camera failed during assignment Message Could not switch camera. An attempt was made to assign a camera that is different from the camera Cause being viewed by a client with control rights of a higher level than yourself. Ask the other client to release the control privilege.
- Page 23 Error Messages (15) Incorrect administrator ID or password (MV level only) Message Administrator ID or password of the camera server is invalid. The administrator ID or password at the camera server has been changed. Cause Action to Change the administrator ID or password at the camera server or at MV LE. be taken (16) Connection cut at camera server Message...
- Page 24 2828, 16th Street, N.E, Calgary, Alberta T2E 7K7 CANON CANADA INC. MONTRÉAL 5990 Côte-de-Liesse, Montréal, Québec H4T 1V7 If you have any questions, call the CANON CANADA Customer Information Centre toll-free at 1-800-OK-CANON (652-2666) (Canada only) MEXICO CANON MEXICANA, S. DE R.L.DE C.V.
