- Page 1 Projector Monitoring Software Ver. 1.0.0 User’s Manual...
-
Page 2: Table Of Contents
Introduction "Projector Monitoring Software" (hereafter referred to as "this software") is a software that uniformly manages network-connected compliant Canon Projectors, via network. Operating conditions and maintenance information of up to 254 projectors can be monitored and managed. This manual describes the introduction of this software, and its routine operation. -
Page 3: Chapter 1 • Introduction
CHAPTER 1 • Introduction CCCCTCC C Introduction Introduction Crocess Prepare for introduction of this software as shown below. Prepare an administrative computer that is C Creparing an administrative connected to a network. Projectors connected to computer the local area network can be managed. If the network is managed under a subnet, network settings on the administrative computer ▼... -
Page 4: System Requirements
CHAPTER 1 • Introduction System Cequirements To install this software on a computer, following requirements must be met. Category Essential Requirements Microsoft Windows XP Professional SP2 or later, Microsoft Windows Vista Ultimate Supported Languages Japanese, English Intel Pentium 4 2.4 GHz or better Memory 1 GB or more Display XGA or more .NET Framework Windows XP: .NET Framework 2.0 SP1 or more... -
Page 5: Configuring The Network Settings Of The Software
CHAPTER 1 • Introduction Configuring the Network Settings of the Software When installation of this software is complete, run the software and configure the discovery settings of the network for discovery. 1.4.1 Starting the Software Click the Windows [Start] menu and select [All Programs], followed by [Projector Monitoring Software] and [Projector Monitoring Software]. Main screen of this software will display. Configuring the Discovery Settings 1.4.2 Configure the network range for discovering projectors. Methods vary depending on "SNMP... - Page 6 CHAPTER 1 • Introduction To configure a broadcast address, select the [Broadcast] tab and click the [New] button. [Specify broadcast discovery settings] dialog will display. Note As default, broadcast settings configured on the network card of the administrative computer will display in the discovery range list. Complete the dialog with necessary information and click the [OK] button. Description Category Broadcast address...
- Page 7 CHAPTER 1 • Introduction Complete the dialog with necessary information and click the [OK] button. Description Category Enter a first IP address in the range for discovery, in "XXX. First address XXX.XXX.XXX" form. Enter a last IP address in the range for discovery, in "XXX.XXX. Last address XXX.XXX" form. Community name Enter a community name within 15 alphanumeric characters and symbols.
- Page 8 CHAPTER 1 • Introduction ■ For LV Series When using LV series, specify an IP address of the projector for discovery. Note With LV series, you can not discover using broadcast addresses or IP address ranges. With LV series, it is recommended to use a fixed IP address for the projector. If DHCP is configured to automatically assign IP addresses, you will need to reconfigure this software everytime the projector's IP address changes. Configure LV series with the following procedures. From [Discovery setting] of the [Option] menu, select [LV series] to configure. [Discovery settings] dialog will display.
- Page 9 CHAPTER 1 • Introduction Complete the dialog with necessary information and click the [OK] button. Description Category IP address Enter an IP address of the projector, in "XXX.XXX.XXX.XXX" form. Enter a port number to be used, in one-byte numbers. Default Port number value is set to "7142." Timeout Enter a number of seconds to time out, from 1 to 9. Note An error message will appear and settings will not be registered if a value of an entry is invalid or insufficient. Correct it as required.
-
Page 10: Configuring The Polling Interval Settings
CHAPTER 1 • Introduction Configuring the Polling Interval Settings 1.4.3 Default polling interval for this software is set to "Not specified" for discovering projectors, and "1 hour" for receiving status of the projector. Change the polling interval with the following procedures. Select [Polling interval settings] from the [Option] menu. [Polling interval settings] dialog will display. Select a polling interval from the pop-up menu beside [Get projector status every] and [Discover projector every], and click [OK]. -
Page 11: Chapter 2 • Routine Operation
CHAPTER 2 • Routine Operation CCCCTCC 2 Coutine Operation Cunning the Software Run this software with the following procedures. Click the Windows [Start] menu and select [All Programs], followed by [Projector Monitoring Software] and [Projector Monitoring Software]. The main screen displaying projector groups and information of recognized projectors will display. Cxiting the Software Exit this software with the following procedures. Select [Exit] from the [Group] menu. -
Page 12: Main Screen
CHAPTER 2 • Routine Operation Main Screen The main screen displays the following information. For operating procedures, see referring pages for details. Menu bar Projector list (see p. 17) Status bar Projector group list (see p. 13) Description Name Displays the function menu. Menu bar Displays projector groups. Projector group list Select a group from the list to display information of corresponding projectors in the Projector list. -
Page 13: Using The Projector Group List
CHAPTER 2 • Routine Operation Using the Crojector Group List 2.4.1 About Projector Groups Projectors connected to the network can be managed in groups using this software. Projector groups vary as described below: Description Type Typical group Typical group that automatically classifies managed projectors depending on its status. - Page 14 CHAPTER 2 • Routine Operation Enter a projector group name, and place a check mark beside necessary projector parameter categories and enter its conditions for classification. It will be a "Status group" if more than one condition is specified, and a "User group" if none is specified. Description Category Projector group Enter a name within 40 one-byte characters. name Product name E n t e r a p r o d u c t n a m e o f t h e p r o j e c t o r u s i n g o n e - b y t e alphanumerical characters.
-
Page 15: Changing Projector Group Settings
CHAPTER 2 • Routine Operation Note An error message will appear and settings will not be registered if a value of an entry is invalid or insufficient. Correct it as required. Entries will be cancelled if [X] (Close) or [Cancel] button is clicked before clicking the [OK] button. 2.4.3 Changing Projector Group Settings You can change the settings of a created "Status group" or "User group." If all conditions in a "Status group" are deleted, it will automatically be a "User group." If more than one condition is specified in a "User group," it will automatically be a "Status group."... -
Page 16: Deleting A Projector Group
CHAPTER 2 • Routine Operation Deleting a Projector Group 2.4.4 "Status group" and "User group" created by the user can be deleted. Note You can not delete the "Typical group." Delete a projector group with the following procedures. Select a projector group to delete from the Projector group list, and select [Delete] from the [Group] menu. Confirm the dialog and click [Yes]. Selected projector group will be deleted. -
Page 17: Using The Projector List
CHAPTER 2 • Routine Operation Using the Crojector List Confirming the Status of a Projector 2.5.1 Confirm detailed properties of a projector shown in the Projector list with the following procedures. Select a projector to confirm the properties from the Projector list, and select [Projector information] from the [Projector] menu. Properties dialog of the selected projector will display. Projector name, location, status, lamp replacement, air filter cleaning and replacement information are displayed in the [Projector information] tab. -
Page 18: Entering Comments
CHAPTER 2 • Routine Operation 2.5.2 Entering Comments Enter comments such as contact numbers and maintenance records in projectors with the following procedures. Select a projector to confirm the properties from the Projector list, and select [Projector information] from the [Projector] menu. Properties dialog of the selected projector will display. Click the comment field to enter comments. Up to 512 one-byte characters can be entered in the comment field. Click [OK] when you have finished entering comments. Entered comments will be saved. -
Page 19: Displaying The Projector Settings Dialog
CHAPTER 2 • Routine Operation Displaying the Projector Settings dialog 2.5.3 Display the web settings dialog of projectors shown in the Projector list with the following procedures. Select a projector from the Projector list, and select [Web link] from the [Projector] menu. Browser will run and display the web settings dialog of the projector. Note For procedures on using the web settings dialog, see the instruction manual that came with the projector. -
Page 20: Discovering Projectors
CHAPTER 2 • Routine Operation ■ Copying Projectors to other User Groups Copy selected projectors to other User groups with the following procedures. Select a projector to copy from the Projector list, and select [Copy] from the [Projector] menu followed by the target User group. Selected projector will copy to the specified User group. -
Page 21: Setting The Protocol Of A Projector
CHAPTER 2 • Routine Operation 2.5.7 Setting the Protocol of a Projector Projectors in the Projector list will display as "Disconnected" if network settings of projectors are changed. In this case, adjust the protocol settings of the projector labelled "disconnected" in accordance with the changed network settings, with the following procedures. Select [Protocol settings] from the [Projector] menu. "Protocol settings" dialog will appear. Select a protocol from the [Protocol] pop-up menu, and adjust the settings. Description Category IP address... -
Page 22: Chapter 3 • Appendix
CHAPTER 3 • Appendix CCCCTCC 3 Cppendix Troubleshooting ■ Error Message Displayed Cause Solution • Software did not start properly, or has not Restart this software. • If an error message continues to appear after been installed properly. restarting, uninstall this software then reinstall it. ■... - Page 23 CHAPTER 3 • Appendix Cause Solution • Configure the discovery settings or protocol settings Network settings of the projector and protocol settings of this software are of this software to match the SNMP settings of the different differently projector. This software cannot communicate with the projector if SNMP version, community name and password do not match.
- Page 24 YT1-1419-000 © CANON INC. 2009...
