  • Page 1 CR9000X Measurement and Control System Overview Revision: 3/07 C o p y r i g h t © 1 9 9 5 - 2 0 0 7 C a m p b e l l S c i e n t i f i c , I n c .

  • Page 3: Table Of Contents

    CR9000X Overview Table of Contents Overview..............OV-1 OV1. Physical Description ..............OV-1 OV1.1 Basic System .................OV-1 OV1.2 Measurement Modules ............OV-3 OV1.3 Communication Interfaces ............OV-7 OV2. Memory and Programming Concepts ..........OV-8 OV2.1 Memory .................OV-8 OV2.2 Measurements, Processing, Data Storage......OV-8 OV2.3 Data Tables................OV-9 OV3.
  • Page 4 CR9000X Overview Table of Contents...

  • Page 5: Overview

    PC via the built-in 10BaseT/100BaseT Ethernet port or the RS-232 port. The CR9032 also has built-in Serial Device for Measurement (SDM) terminals and a CSI 9-pin port for communication with Campbell Scientific peripherals. The SDM 12 volt supply is current limited to 1.85 amps.
  • Page 6 Overview MEASUREMENTS: Analog Output Peripheral (AO4) CANBus Interface Peripheral (CANBUS) CSAT3 Sonic Anemometer (CSAT3) DSP4 Display (DSP4) I/O Port Peripheral (CD16AC) Interval Timer Peripheral (INT8) Output Data to PC Card (CardOut) Serial Input/Output Peripheral (SIO4) Switch Closure Measurement Peripheral (SW8A) +12 G C1 C2 C3 RS-232 CS I/O...

  • Page 7: Ov1.2 Measurement Modules

    Overview MEASUREMENTS: Battery (voltage and current) CONTROL: PowerOff ON OFF CHARGE(9-18VDC) 12VOUT POWER UP POWER CHARGE 9011 POWER SUPPLY MADE IN USA >2.0V <0.8V FIGURE OV1-4. CR9011 OV1.2 Measurement Modules CR9050 Analog Input Module The CR9050 Analog Input Module has 14 differential or 28 single-ended inputs for measuring voltages up to ±5 V.
  • Page 8 Overview CR9051E Fault Protected 5 V Analog Input Module The number of channels and measurements are the same as for the CR9050 Analog Input Module. Each input channel is fault-protected so as to permit over-voltages between +50 V and –40 V without corruption of measurements on other input channels.
  • Page 9 Overview MEASUREMENTS: VoltFilt FFTFilt SHORT SHORT SHORT SHORT SHORT SHORT OPEN OPEN OPEN OPEN OPEN OPEN CH 1 CH 2 CH 3 CH 4 CH 5 CH 6 CR9052IEPE MADE IN USA FIGURE OV1-8. CR9052IEPE CR9058E Isolation Module The CR9058E is a 10-channel, differential input isolation module. Each channel has a 24-bit A/D converter which supplies input isolation for up to ±60 V continuous common mode voltage conditions.
  • Page 10 Overview Normally thermocouple measurements would be made on the CR9050 Analog Input Module (±5 Volt) because of its greater resolution, however they can be made on the CR9055 if the ±50 V common mode range is necessary. Thermocouple, Differential Voltage (TCDiff) Thermocouple, Single-Ended Voltage (TCDiff) 9055 50V ANALOG INPUT MADE IN USA...

  • Page 11: Ov1.3 Communication Interfaces

    Overview MEASUREMENTS: Count Pulses or Frequency (PulseCount) Read State of I/O Channels (ReadI/O) Write to I/O Channels (WriteI/O) DIGITAL I/O LOW LEVEL AC SWITCH CLOSURRE 12 13 15 16 9070 COUNTER & DIGITAL I O MADE IN USA FIGURE OV1-12. 9070 CR9071E Counter and Digital I/O Module Features 12 channels capable of high-level (5 V square wave) pulse counting at frequencies up to 1 MHz.

  • Page 12: Ov2. Memory And Programming Concepts

    Overview PC9000's Terminal Mode can also be used. Set the Comm window to your computer’s Comm port and set the baud rate to 115200. With a serial cable hooked between your PC's and CR9000X's RS-232 ports, press the test button to ensure that you have established communications.

  • Page 13: Ov2.3 Data Tables

    Overview Processing Task: Measurement Task: Digital I/O task Analog measurement and excitation sequence and Read and writes to ports and counters on CR9071 timing (ReadIO, WriteIO, TimerIO) Sets ports on 9060 Excitation Module (SetPort) Sends interrupt to Processor task that reads and sets Processes measurements ports/counters.

  • Page 14: Ov3.2 Pc9000 Installation

    Overview OV3.2 PC9000 Installation To install the PC9000 software: • Start Microsoft Windows 2000, NT, or XP • Insert CD • From the Program Manager, select File menu and choose Run • Type (disk drive):\setup and press Enter , e.g., a:\setup<Enter> •...
  • Page 15 Overview File Edit Realtime Analysis Tools Collect Display Windows Help Data Retrieval . . . Collect data from CR9000 Scheduled Data Retrieval . . . CommLink Select Series Linked Station . . . Select Parallel Linked Station . . . PC to CR9000 Logger Clock .
  • Page 16 Overview File Edit Realtime Analysis Tools Collect Display Windows Help Colors . . . Change fonts Undo Ctrl + Z Fonts . . . and/or Colors for Date & Time Defaults . . . Active Windows. Select All Ctrl + X Editing Options for Copy Ctrl + C...
  • Page 17 Overview RealTime Alarms List Allows the display of up to 20 fields from a single data table. Two alarm conditions can be created for each field by double clicking the left mouse button while the cursor is held over the field number. After the alarm parameters are set-up, they can be saved to and subsequently loaded from an .alm file.
  • Page 18 Overview Basic 3-D Histogram Allows the display of histograms in a real-time 3D format. The 3rd dimension is based on the record number. You can set the number of histogram records that you wish to monitor in a single histogram graph. Rainflow Histogram Allows the display of RainFlow Histograms in real-time.

  • Page 19: Ov4. Specifications

    Electrical specifications are valid over a -25° to +50°C range unless otherwise specified; testing over -40° to +70°C available as an option, excluding batteries. Non-condensing environment is required. To maintain specifi- cations, Campbell Scientific recommends recalibrating dataloggers every two years. CR9032 CPU MODULE...
  • Page 20 ACCURACY: ± (0.2% of output ±4 mV) RESOLUTION: 12-bit A/D (2.4 mV) We recommend that you confirm system configuration and critical specifications with OUTPUT CURRENT: ±50 mA Campbell Scientific before purchase. Copyright © 2004 Campbell Scientific, Inc. Printed May 2004 OV-16...
  • Page 21 Overview CR9052DC Specifications Operating temperature range is -40° to +70°C (specifications valid over this range unless otherwise specified). Non-condensing environment required. To maintain specifications, yearly recalibrations are recommended. Inputs Number of differential input channels: Programmable anti-aliasing implemented with finite-impulse-response filters Output sample rate programmable: 50 ksamples s to 5 samples s...
  • Page 22 CR9052ECs and simply move the CR9000 and on-board CR9052DC(s) between monitoring locations. We recommend that you confirm system configuration and critical specifications with Campbell Scientific before purchase. C opyr i ght © 2000 C am pbel l Sci ent i f i c, I nc.
  • Page 23 This is a blank page.
