Installation

To install the monitor on your host system, please follow the steps below:
Steps
1
Connect the video cable
a Make sure both the monitor and computer are switched off.
b Connect the VGA video cable to the computer.
c Connect the digital cable
(1) Make sure both the monitor and computer are switched off.
(2) DVI Cable (Optional, only Dual-Input Model)
a. Make sure both the monitor and computer are powered-OFF.
b. Connect the DVI cable to the computer.
(3) HDMI Cable (Optional, only HDMI-Input Model)
a. Make sure both the monitor and computer are powered-OFF.
b. Connect the HDMI cable to the computer.
2
Connect the adapter
a Connect the AC cord to the adapter.
b Connect one end of the adapter to the monitor and the other end to a properly
grounded, AC outlet.
3
Turn on the monitor and computer
Turn on the monitor first, then the computer. This sequence is very important.
4
If the monitor does not function properly, please refer to the troubleshooting
section to diagnose the problem.
2
HDMI
DVI
D-SUB
DVI
HDMI
DVI
D-SUB
DC-IN
HDMI
2
DC
D-SUB
DC-IN
7
