- Page 1 MODEL FMS60 OWNER/OPERATOR MANUAL Berkel Company PO Box 696 2006 Nor thwestern Parkway Louisville, Kentucky 40201 (800) 348 - 0251 Fax 888 - 888 -2838 F37246 Rev. B (July 2010)
-
Page 2: Table Of Contents
Wire Cage/Bowl Guard ..........................8 Remove Wire Cage/Bowl Guard ....................8 Install Wire Cage/Bowl Guard ....................8 CLEANING ..........................8 MIXING BOWL CAPACITY CHART ...................9 Agitators and Accessories ......................10 MAINTENANCE ........................10 Motor ............................10 Bowl Lift Slideways .........................10 SERVICE ..........................11 WARRANTY ..........................12 ©Berkel, 2010 – 2 –... -
Page 3: General
INSTALLATION, OpErATION, ANd CArE OF BErKEL FMS60 QuArT MIXEr SAVE THESE INSTruCTIONS GENErAL The 60 quart mixer has an AC Induction electric motor and motor control. A 60 quart bowl, B-Flat beater, bowl guard, spiral dough hook, D wire whip, bowl truck, and ingredient chute are shipped as standard equipment. -
Page 4: Electrical Connections
Connect ground wire to ground lug on the mixer. Assure all wires and wire connections are inside wiring area and away from belt. For wiring details, reference wiring diagram located on the inside of the TOP COVER. Reinstall TOP COVER. FMS60 Owner/Operator Manual – 4 –... -
Page 5: Operation
Moving beater in bowl. Keep hands, clothing and utensils out while in operation. do not use without interlocked guard. Controls Attachment Hub Thumb Screw and plug Bowl Lift Handle Bowl Guard/ Wire Cage Splash Guard Bowl Support Agitator Fig. 1 FMS60 Owner/Operator Manual – 5 –... -
Page 6: Controls
The Bowl Lift Handle (Fig. 1) is used to raise and lower the bowl. For the FMS60 (60 QUART) Mixer, to raise the bowl, rotate the handle clockwise; rotating the handle counterclockwise lowers the bowl. FMS60 Owner/Operator Manual – 6 –... -
Page 7: Mixing
Close bowl guard/wire cage and raise bowl support to mix position, move the speed select knob to the desired speed and start the mixer to operate the attachment. If bowl support is lowered off the mix position, mixer will stop FMS60 Owner/Operator Manual – 7 –... -
Page 8: Wire Cage/Bowl Guard
NOT use a hose to clean the mixer — it should be washed with a clean damp cloth. Clean the bowl guard/wire cage by wiping with a cloth or sponge and warm soapy water. dO NOT place agitators, attachments or mixer components in a dishwasher for cleaning. FMS60 Owner/Operator Manual – 8 –... -
Page 9: Mixing Bowl Capacity Chart
Above capacity based on 12% flour moisture and 70°F water temperature. ABBREVIATIONS - AGITATORS SUITABLE FOR OPERATION B - Flat Beater D - Wire Whip ED - Spiral Dough Hook FMS60 Owner/Operator Manual – 9 –... -
Page 10: Agitators And Accessories
The motor has sealed ball bearings which require no lubrication maintenance. BOWL LIFT SLIdEWAYS The bowl lift slideways (Fig. 6) should be lubricated once each month. Apply a light coat of a "Food Grade" grease to both sides of the slideways. Slideway Fig. 6 FMS60 Owner/Operator Manual – 10 –... -
Page 11: Service
You can go online to www.berkelequipment.com and click on the SERVICE TAB. Then, simply enter your zip code and you will be provided with a list of local Hobart and Designated Berkel Service locations to call for service, parts and technical support. -
Page 12: Warranty
Berkel's obligation and liability under this warranty is expressly limited to repairing or replacing equipment that proves to be defective in material or workmanship within the applicable warranty period. Berkel or a Designated Berkel Service Location will perform all repairs pursuant to this warranty. Berkel expressly...
