Berkel PM60 Specifications

Model PM60
Safety and Convenience Features
Berkel Model PM60 planetary mixer is a heavy-duty,
precision crafted, versatile machine. This all-purpose
mixer uses a powerful, planetary mixing action to
thoroughly blend, mix and aerate all ingredients
with consistent and predictable results. The wide-
faced, hardened alloy steel helical gears deliver
energy at pre-selected fixed speeds. Models are
available with a selection of optional bowls to
provide additional capacity and flexibility. The
heavy-duty, stainless steel, wire front bowl guard
opens easily for adding ingredients. The bowl guard
interlock prevents the mixer from running if guard is
opened or the bowl is lowered. The units feature
moisture resistant switches, No-Volt Release and
99-minute timers that automatically shut off the
machines in any speed after the predetermined
time has elapsed.
Accessories
!
VSPH - #12 Taper Hub; Vegetable Slicer/Grater
!
FCMC - #12 Taper Hub; Meat Grinder
!
Bowl Scraper
!
Reduction Set
Approved By:
Date
Berkel Company • 4406 Technology Drive • South Bend, IN 46628-9700
574-232-8222 • 800-348-0251 • FAX 888-888-2838 • www.berkel.com
Form #SPC27-05 06R
Item #
Model PM60
Planetary Mixer
!
PM60 60 Qt. Floor Model
Standard Features
! !
Model PM60 60-Qt . Mixer with 3-speed, 4 HP
(continuous duty), totally enclosed, and permanently
lubricated, thermally protected motor; furnished in
220/60/1, 20 amp, AC, ETL listed; also available in
220/60/3 and 220/50/1, ETL listed
!
Wide-faced, hardened alloy stee , h
sealed in lubricant with hea
clutch combine for highly dependab , q
!
3 Pre-selected, fixed speeds on the PM60
!
Manual bowl lift is wheel operated
!
99 minute timer for continuous or timed operation,
automatically shuts off the machine in any speed after
the pre-determined time has elapsed.
!
#12 T aper hub on the for use with any #12 size attach-
ments
!
Flat Batter Beater, Wire Whip, Spiral Dough Hook and Bowl Dolly
!
Bowl Guard with interlock prevents the mixer from running
if guard is opened
!
No-Volt Rellease prevents activation of the mixer in the
event of a power interruption; operator must restart the
mixer
!
Highly reliable, moisture resistant stop and start switches
!
Welded steel frame construction; finish is silver metallic
epoxy powder coat enamel for easy cleaning
!
Attached 6-foot, flexible, 3-wire cord
Options
!
220/60/3 AC, ETL listed
!
220/50/1 AC, ETL listed
!
Power Bowl Lift
l elical gears fully
v d y uty ball bearings and -
le uiet operation
